Silver 2U rack server with twelve front 3.5-inch drive bays

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2× Xeon E5-2680 v4 14-core 32GB DDR4 12× 3.5" bays

SKU CH-27BW-EFAYK

2U rack server with two 14-core Xeon E5-2680 v4 processors, 32GB DDR4 ECC memory, twelve 3.5-inch hot-swap drive bays, MegaRAID 9361-8i controller, quad 10GBase-T ports and dual 1000W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual Xeon E5-2680 v4 deliver 28 cores at 2.4 GHz base with 3.3 GHz turbo
  • 32 GB DDR4 ECC memory across 4 modules supports demanding virtualization workloads
  • MegaRAID 9361-8i controller provides 8 SAS ports with RAID 0, 1, 5, 6, 10, 50, 60
  • 12 hot-swap 3.5 inch drive bays accept SAS or SATA drives for flexible storage
  • Quad 10GBase-T ports via Intel X540 plus IPMI 2.0 enable high-speed networking and remote management

Dual 14-core Xeon E5-2680 v4 2U server

The Supermicro SYS-6028U-TR4T+ is a 2U rackmount server built around two Intel Xeon E5-2680 v4 processors. Each CPU runs at 2.4 GHz base with 3.3 GHz turbo across 14 cores. The system ships with 32 GB of DDR4 2400 MHz registered ECC memory installed across four slots. It targets workloads that need high thread counts and memory reliability such as virtualization hosts, database nodes and compute clusters.

Sustained load with redundant titanium power

Dual 1000 W titanium-efficiency power supplies share the load and keep the system running if one unit fails. Hot-swap drive bays and the MegaRAID 9361-8i controller with 1 GB cache and battery-backed write-back let you replace drives or rebuild arrays without downtime. IPMI 2.0 with dedicated LAN provides KVM-over-LAN and virtual media so administrators can monitor thermals, power and POST progress remotely during extended heavy utilisation.

12-bay SAS/SATA limit and 8-port RAID constraint

Twelve 3.5-inch hot-plug bays accept SAS or SATA drives but the installed MegaRAID 9361-8i connects only eight ports directly. Expanding past eight drives requires an additional HBA or expander not included. The quad-port Intel X540 10GBase-T adapter delivers 10 GbE over copper RJ45; maximum link distance follows the 10GBase-T standard. Memory capacity can grow to 1.5 TB using all 24 DIMM slots with registered ECC DDR4 modules.

Highlights

  • Dual Xeon E5-2680 v4 deliver 28 cores at 2.4 GHz base with 3.3 GHz turbo
  • 32 GB DDR4 ECC memory across 4 modules supports demanding virtualization workloads
  • MegaRAID 9361-8i controller provides 8 SAS ports with RAID 0, 1, 5, 6, 10, 50, 60
  • 12 hot-swap 3.5 inch drive bays accept SAS or SATA drives for flexible storage
  • Quad 10GBase-T ports via Intel X540 plus IPMI 2.0 enable high-speed networking and remote management

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2680 V4
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

How much power do the dual 1000 W supplies draw under full load?

The server includes two 1000 W Titanium-efficiency power supplies; actual draw depends on workload and installed drives.

Which drives and caddies must I supply myself?

The 12 hot-swap 3.5" bays accept SAS or SATA drives; trays are included but no drives are installed.

Will the X540 10GBase-T ports negotiate down to 1 GbE switches?

Yes, the four RJ45 10GBase-T ports auto-negotiate to 1 GbE when connected to slower switches.
