Silver 2U rack server front with twelve 3.5-inch drive bays

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2× Xeon E5-2680 v4 14-core 2.4 GHz 512 GB DDR4 12× 3.5″ bays

SKU CH-G9NM-3RB6E

A 2U dual-socket rack server with two 14-core Xeon E5-2680 v4 CPUs, 512 GB DDR4 ECC memory, 12 hot-swap 3.5″ SATA/SAS bays, quad 10GBase-T ports and redundant 1000 W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual Xeon E5-2680 v4 processors with 28 total cores handle heavy workloads
  • 512 GB DDR4 ECC memory across 16 DIMM slots supports large datasets
  • 12 hot-swap 3.5″ drive bays provide flexible SAS or SATA storage capacity
  • Quad 10GBase-T ports via Intel X540 deliver high-speed network throughput
  • IPMI 2.0 with KVM-over-LAN enables full remote server management

Dual-socket Xeon server for virtualisation

This 2U rackmount system arrives with two Intel Xeon E5-2680 v4 processors, each running 14 cores at 2.4 GHz with a 3.3 GHz turbo. The 512 GB of DDR4 2400 MHz registered ECC memory is installed across 16 modules, leaving 8 DIMM slots free for expansion up to 1.5 TB. It targets teams that need high core counts and large memory capacity for virtualisation hosts, database clusters or cloud workloads.

Twelve hot-swap bays and quad 10GBase-T networking

The chassis provides 12 front-accessible 3.5″ trays for SATA or SAS drives, backed by an LSI MegaRAID 9361-8i controller that supports RAID 0, 1, 5, 6, 10, 50 and 60 with 1 GB cache and battery backup. Four RJ45 10GBase-T ports from the Intel X540 adapter deliver high-throughput networking without extra cards. A dedicated IPMI 2.0 LAN port enables KVM-over-LAN and virtual media for full out-of-band management.

Redundant titanium power supplies sustain

Dual 1000 W titanium-efficiency power supplies share the load and allow hot-swap replacement, keeping the system running during maintenance or a unit failure. The power design supports sustained operation of both CPUs, full memory population and a full complement of spinning drives without throttling. The Matrox G200 graphics with 8 MB video memory handles console output only, so GPU compute tasks are not supported.

Highlights

  • Dual Xeon E5-2680 v4 processors with 28 total cores handle heavy workloads
  • 512 GB DDR4 ECC memory across 16 DIMM slots supports large datasets
  • 12 hot-swap 3.5″ drive bays provide flexible SAS or SATA storage capacity
  • Quad 10GBase-T ports via Intel X540 deliver high-speed network throughput
  • IPMI 2.0 with KVM-over-LAN enables full remote server management

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2680 V4
Installed Memory Size512GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

How far can the 512 GB DDR4 memory be expanded on this server?

The board provides 24 DIMM slots and supports up to 1.5 TB of DDR4 ECC registered memory.

What is the noise and heat profile when the dual 1000 W titanium supplies run continuously?

Redundant hot-swap titanium supplies share the load, reducing fan speed and heat output during sustained operation.

Which drives must I supply to populate the 12 hot-swap bays?

The chassis includes 12 empty 3.5″ SAS/SATA trays; you provide the hard drives or SSDs.
