Silver 2U rack server with twelve front drive bays and dual power supplies

Supermicro

Supermicro SYS-6028U-TR4T+ 2U rack server 2× Xeon E5-2660 v4 14-core 512GB DDR4 12× 3.5" bays

SKU CH-FFWA-E357T

Dual 14-core Xeon server with 512GB DDR4, 12 hot-swap 3.5" bays, quad 10GbE and redundant 1000W supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual Xeon 14-core CPUs deliver 28 threads for heavy workloads
  • 512 GB DDR4 ECC memory supports large datasets and virtualization
  • 12 hot-swap 3.5" bays provide high-capacity SAS or SATA storage
  • Quad 10GBase-T ports enable fast network throughput
  • Redundant 1000 W power supplies maintain uptime during failures

Dual 14-core Xeon 2U rack server

The Supermicro SYS-6028U-TR4T+ is a 2U rackmount server system fitted with two Intel Xeon E5-2660 v4 processors. Each CPU runs at 2.0 GHz with 14 cores and a 3.2 GHz turbo frequency. The platform includes 512 GB of DDR4 registered ECC memory across 16 modules and an LSI MegaRAID 9361-8i controller with 1 GB cache. Twelve hot-swap 3.5-inch drive bays accept SATA or SAS disks for high-capacity storage arrays.

Suited for virtualization and database hosts.

This server targets environments that need dense CPU threads, large memory capacity and redundant 10 GbE networking in a 2U form factor. The quad-port Intel X540 adapter and IPMI 2.0 with KVM-over-LAN support remote management and high-throughput data paths. Buyers who require PCIe GPU slots, more than twelve drive bays or a different drive form factor should look at other configurations.

12 hot-swap 3.5-inch bays with SAS/SATA RAID

The single specification that decides fit is the twelve 3.5-inch hot-swap bays backed by the MegaRAID 9361-8i controller supporting RAID 0, 1, 5, 6, 10, 50 and 60. This combination determines how many mechanical drives can be installed and which redundancy levels are available without adding external enclosures or a second controller.

Highlights

  • Dual Xeon 14-core CPUs deliver 28 threads for heavy workloads
  • 512 GB DDR4 ECC memory supports large datasets and virtualization
  • 12 hot-swap 3.5" bays provide high-capacity SAS or SATA storage
  • Quad 10GBase-T ports enable fast network throughput
  • Redundant 1000 W power supplies maintain uptime during failures

Specifications

BrandSUPERMICRO
SeriesCSE-829UAC-R1K02-T
ModelSYS-6028U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2660 V4
Installed Memory Size512GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSuperMicro AOC-2UR-6-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What rack space and mounting hardware does the 2U SYS-6028U-TR4T+ require?

The server occupies 2U of rack height and uses the Supermicro CSE-829UAC-R1K02-T chassis; front bezel and rack-mount rails are not included and must be sourced separately.

How is the MegaRAID 9361-8i controller installed, and what step is often missed?

The 9361-8i comes pre-installed in a PCIe slot with its 1 GB cache module and battery backup already connected; the step often missed is enabling the cache in the controller BIOS before creating virtual drives.

Which components in the SYS-6028U-TR4T+ will need replacement over time?

The two hot-swap 1000 W power supplies, the 12 drive trays, the MegaRAID 9361-8i cache battery, and the CMOS cell on the motherboard are the parts most likely to require replacement during the server's service life.
