Green rectangular circuit board with metal bracket and mounting holes

Supermicro

Supermicro BKT-BBU-BRACKET-05 RAID controller battery bracket

SKU CH-76N1-XGZB2 MPN BKT-BBU-BRACKET-05

Mounting bracket for LSI iBBU06, iBBU07, iBBU08 and iBBU09 battery backup units

  • Securely mounts RAID cache battery to controller
  • Compatible with LSI iBBU06, 07, 08, 09 and CacheVault modules
  • Requires LSI00260 cable for iBBU06, 07, 08 units
  • Compact 6.0 x 6.0 x 2.0 inch form factor fits tight server chassis
  • Lightweight 1.0 lbs design adds minimal load to board

RAID controller battery bracket

This Supermicro BKT-BBU-BRACKET-05 is a mounting board for LSI cache backup modules. It secures the iBBU06, iBBU07, iBBU08 and iBBU09 battery units as well as all CacheVault power modules. The bracket is sold new and ready for integration into compatible server configurations.

Compatibility and constraints

The bracket requires the LSI00260 cable for iBBU06, iBBU07 and iBBU08 units. When using iBBU08 with 9260-4i or 9260-8i controllers the same cable is also mandatory. Builders who lack the LSI00260 cable or who use unsupported battery models should look elsewhere.

Physical specifications

Dimensions are 6.0 by 6.0 by 2.0 inches, which equals 15.2 by 15.2 by 5.0 centimetres. Weight is 1.0 lbs or .45 kg. Verify that your chassis can accommodate these measurements before purchase.

Highlights

  • Securely mounts RAID cache battery to controller
  • Compatible with LSI iBBU06, 07, 08, 09 and CacheVault modules
  • Requires LSI00260 cable for iBBU06, 07, 08 units
  • Compact 6.0 x 6.0 x 2.0 inch form factor fits tight server chassis
  • Lightweight 1.0 lbs design adds minimal load to board

Specifications

No published specifications for this item yet.

Questions about this item

Which LSI battery backup units are compatible with the BKT-BBU-BRACKET-05?

It supports LSIiBBU06, LSIiBBU07, LSIiBBU08 and LSIiBBU09 as well as all LSI CacheVault Power Modules.

What are the physical dimensions of the BKT-BBU-BRACKET-05?

The bracket measures 6.0 x 6.0 x 2.0 inches or 15.2 x 15.2 x 5.0 cm and weighs 1.0 lbs / 0.45 kg.

Does the BKT-BBU-BRACKET-05 require any additional parts to mount an LSIiBBU08 on a 9260-4i or 9260-8i controller?

Yes, the LSIiBBU08 needs the LSI00260 cable when used with 9260-4i or 9260-8i controllers.
