White wall-mounted sensor with black rectangular housing and curved lens cover

Sunydog FBMRICHS4066BXUSMF Wired Dual-Tech PIR Microwave Sensor 7.6m x 9m 24.125GHz Pet Immune White

SKU CH-9TJW-ST9K7

Wired dual-tech PIR and microwave detector covers 7.6m x 9m with pet immunity and 24.125GHz K-band for fewer false alarms

  • location/usageWall Mount
  • finishBlack
  • weight150 grams
  • size dimensions43 mm x 75 mm x 43 mm
  • Dual PIR and microwave detection covers 7.6m x 9m area
  • Pet immunity prevents false triggers from small animals
  • K-band microwave technology suppresses false alarms and boosts sensitivity
  • Temperature compensation ensures reliable operation from -15 to 55°C
  • ABS housing provides shock resistance and durability for wall mounting

Product Identity

The Sunydog FBMRICHS4066BXUSMF is a wired dual-technology detector combining passive infrared and microwave sensing for home burglar alarm systems. It suits installers and homeowners who need reliable intrusion detection with pet immunity in a wall-mounted format.

Pre-Installation Checks

Verify that your alarm panel supplies 7.5V to 16V DC and can accept a normally closed relay contact rated at 30V DC, 500mA. Ensure the mounting location avoids direct sunlight and heat sources, and that the operating temperature range of -15°C to 55°C matches the intended environment.

Build Integration

The sensor covers a 7.6m by 9m area at 24.125GHz microwave frequency and includes anti-white-light protection up to 6500LX. Its ABS housing resists shock and operates in 5% to 95% relative humidity. The unit requires wired connections for power, alarm relay and anti-tamper switch, freeing the system from wireless interference concerns.

Highlights

  • Dual PIR and microwave detection covers 7.6m x 9m area
  • Pet immunity prevents false triggers from small animals
  • K-band microwave technology suppresses false alarms and boosts sensitivity
  • Temperature compensation ensures reliable operation from -15 to 55°C
  • ABS housing provides shock resistance and durability for wall mounting

Specifications

ModelSunydog FBMRICHS4066BXUSMF
location/usageWall Mount
finishBlack
weight150 grams
size dimensions43 mm x 75 mm x 43 mm

Questions about this item

What does the package include and is any wiring or power supply sold separately?

The box contains one wired PIR sensor and one user manual. A 7.5V-16V DC power source and alarm wiring are not included and must be sourced separately.

There is only one model listed; how do I confirm it matches my system voltage and detection needs?

The single model FBMRICHS4066BXUSMF operates on 7.5V-16V DC at 25mA, covers 7.6m x 9m, uses 24.125GHz microwave frequency and provides pet immunity up to 10kg.

What does the 7.6m x 9m detection range mean when the sensor is mounted on a real wall?

At the recommended height the dual-tech sensor creates a 7.6m by 9m volumetric pattern; both PIR and 24.125GHz microwave must trigger together, reducing false alarms from pets or temperature shifts.
