Green PCB quad-port Gigabit Ethernet card with Intel I350 chipset and low-profile bracket

STARTECH

STARTECH ST4000SPEXI 4-Port Gigabit Network Card

SKU CH-XZRG-3EK8P MPN ST4000SPEXI

Adds four Gigabit Ethernet ports via a single PCI Express x4 slot using an Intel I350 chipset

  • StandardsIEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 10
  • Speed10/100/1000Mbps
  • Connectors4 x RJ45
  • Interface4 x PCI Express x4
  • LEDs4 x 100/1000 Mbps Indicator 4 x Link / Activity
  • Wake On LANYes
  • Adds four Gigabit ports through one PCI Express slot
  • Intel I350 chipset delivers 1000 Mbps per port
  • Supports IEEE 802.1Q VLAN tagging for network segmentation
  • Includes low-profile bracket for compact chassis builds
  • 2000 MB/s bandwidth over PCIe x4 interface

Four-port Gigabit server upgrade

The StarTech ST4000SPEXI adds four RJ-45 Gigabit Ethernet ports to a client, server or workstation through a single PCI Express x4 slot. It uses an Intel I350-AM4 chipset and supports 10, 100 and 1000 Mbps speeds with IEEE 802.3x flow control and 802.1Q VLAN tagging. A low-profile bracket is included for compact chassis.

Sustained multi-port throughput

Each port negotiates independently at 10, 100 or 1000 Mbps full duplex, so simultaneous traffic on all four links can approach the 2000 MB/s PCIe x4 bandwidth ceiling. The Intel controller offloads checksum and segmentation tasks, keeping CPU utilisation low during continuous file transfers or virtual-machine bridging. LEDs show link status and 100/1000 Mbps speed per port.

PCIe x4 slot requirement

The card requires an open PCI Express x4 slot (or larger) to deliver its rated 2000 MB/s host bandwidth. Systems limited to x1 or x2 electrical connections will restrict total aggregate throughput across the four ports. Verify slot availability and form-factor clearance before purchase.

Highlights

  • Adds four Gigabit ports through one PCI Express slot
  • Intel I350 chipset delivers 1000 Mbps per port
  • Supports IEEE 802.1Q VLAN tagging for network segmentation
  • Includes low-profile bracket for compact chassis builds
  • 2000 MB/s bandwidth over PCIe x4 interface

Specifications

BrandStarTech.com
ModelST4000SPEXI
StandardsIEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
IEEE 802.1Q VLAN Tagging
IEEE 802.3x Full Duplex Flow Control
Speed10/100/1000Mbps
Connectors4 x RJ45
Interface4 x PCI Express x4
LEDs4 x 100/1000 Mbps Indicator
4 x Link / Activity
Wake On LANYes
FeaturesAdd four Gigabit Ethernet ports to server or workstation through a single PCI Express slot
4-port Gigabit Ethernet network card with Intel I350-AM4 Chipset
Quad-port network adapter card with Intel Chipset and Intel Virtualization Technology
4-port Ethernet network adapter card
PCIe 10 / 100 / 1000 Network Card
PXE network boot support
Auto MDIX and Auto Negotiation Support
Wake-on-LAN
9K jumbo frame support
Dimensions0.71" x 5.20" x 4.72"
Weight0.21 lb.
Package Contents1 x 4 Port Network Card
1 x Low Profile Bracket
1 x Instruction Manual
Shipping weight0.16 kg
Package size165 × 142 × 28 mm

Questions about this item

How much power does the Intel I350-AM4 chipset draw when all four ports run at 1000 Mbps all day?

The card uses a single PCI Express x4 slot and the Intel I350-AM4 chipset is designed for efficient operation in servers and workstations running continuously.

Does my system need a PCI Express x4 slot and four RJ45 cables to use all four ports?

Yes, the adapter requires one PCI Express x4 slot and each of the four ports uses a standard RJ45 connector for twisted-pair cable.

Will the card negotiate 10 Mbps or 100 Mbps links on older switches that only support IEEE 802.3 and 802.3u?

The adapter supports IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX and IEEE 802.3ab 1000BASE-T so it will automatically negotiate the highest speed the link partner offers.
