Dual-port 10G PCIe network card with Intel X550 chipset, low-profile bracket included

STARTECH

STARTECH ST10GPEXNDPI dual-port 10G network card

SKU CH-HYJN-23QFM MPN ST10GPEXNDPI

Dual-port 10GBASE-T network card with Intel X550 chipset supports 10G, 5G, 2.5G, 1G and 100 Mbps over twisted pair cable up to 100 metres

  • StandardsIEEE 802.3an (10GBASE-T), IEEE 802.3ab (1GBASE-T), IEEE 802.
  • Speed10Gbps
  • InterfacePCI-Express
  • TemperatureOperating Temperature:5 ~ 50 degree Celsius (41 ~ 122 degree
  • Humidity20% ~ 80% RH
  • Features2-port 10GBase-T/NBASE-T network card supporting five networ
  • Dual 10GbE ports boost server throughput using Intel X550 chipset
  • Five selectable speeds from 10G down to 100Mbps suit mixed networks
  • PCIe 3.0 x4 lane width feeds full bandwidth to applications
  • Energy-efficient 802.3az design cuts power draw under load
  • Low-profile bracket included fits compact chassis without extra parts

Dual-port 10G PCIe 3.0 card

The StarTech ST10GPEXNDPI adds two 10GBASE-T Ethernet ports through a single PCI Express 3.0 slot. It is built on the Intel X550 chipset and supports five speeds from 100 Mbps to 10 Gbps over twisted-pair copper cable. The half-height design fits standard and low-profile chassis.

Suited for servers needing multi-gigabit uplinks

This adapter targets IT teams upgrading rackmount servers or high-throughput workstations to 10 Gigabit Ethernet without fibre cabling. It does not serve builds that require SFP+ direct-attach or fibre transceivers. Buyers needing single-port density or fibre media should look at a different interface type.

PCI Express 3.0 x4 electrical interface

The card operates on a PCIe 3.0 x4 electrical link, which determines whether the host platform can deliver full 10 Gbps throughput on both ports simultaneously. Verify the slot wiring in the target system before purchase.

Highlights

  • Dual 10GbE ports boost server throughput using Intel X550 chipset
  • Five selectable speeds from 10G down to 100Mbps suit mixed networks
  • PCIe 3.0 x4 lane width feeds full bandwidth to applications
  • Energy-efficient 802.3az design cuts power draw under load
  • Low-profile bracket included fits compact chassis without extra parts

Specifications

BrandStarTech.com
ModelST10GPEXNDPI
StandardsIEEE 802.3an (10GBASE-T), IEEE 802.3ab (1GBASE-T), IEEE 802.3u (100BASE-T)
PCI Express Rev 3.0
Speed10Gbps
InterfacePCI-Express
TemperatureOperating Temperature:5 ~ 50 degree Celsius (41 ~ 122 degree Fahrenheit)
Storage Temperature: -20 ~ 60 degree Celsius (-4 ~ 140 degree Fahrenheit)
Humidity20% ~ 80% RH
Features2-port 10GBase-T/NBASE-T network card supporting five network speeds: 10G, 5G, 2.5G 1G and 100 Mbps
Reliable performance with Intel X550 chipset
IEEE 802.3az compliant energy-efficient chipset
Virtualization (Microsoft Hyper-V) and iSCSI support
PXE support
PCIe 3.0 x4 interface
Supports 2.5 and 5Gbps network speeds on Cat5e cabling, and 10Gbps on Cat6a
Up to 9K jumbo frame support
Supports 802.1q VLAN Tagging
Full-duplex support
Supports Auto-MDIX
Supports checksum offload (IP, TCP, UDP) and large send offload
Configured with a standard-profile bracket, includes a low profile / half
Dimensions0.70" x 4.70" x 5.90"
Weight0.47 lb.
Package Contents1 x network card
1 x low-profile bracket
1 x quick-start guide
Shipping weight0.18 kg
Package size206 × 142 × 41 mm

Questions about this item

How much power does the Intel X550 chipset draw during sustained 10 Gbps traffic?

The IEEE 802.3az compliant chipset reduces power during low utilisation, but the supplier data does not quote a maximum wattage figure.

What must the host system provide for the card to operate at full speed?

A PCI Express 3.0 x4 slot and two Category 6a or better twisted-pair cables are required for 10 Gbps links up to 100 metres.

Will the low-profile bracket let me keep the card in a 1U rackmount chassis?

Yes, the included low-profile bracket fits standard 1U height, and the card dimensions of 0.70 by 4.70 by 5.90 inches are compatible with typical 1U depth.
