STARTECH
STARTECH DKT30CSDHPD3 docking station USB-C 4K HDMI 3 USB 3.0 SD GbE 60W PD 3.0
Connects a 4K HDMI display, wired network, three USB 3.0 devices and SD cards while passing 60 W power to the laptop
- ColorSpace Gray
- CompatibilityOS Compatibility Windows 7, 8, 8.1, 10 Mac OS 10.11 to 10.13
- Ports Spec1 x USB Type-C (24 pin) USB 3.0 Male 1 x HDMI (19 pin) Femal
- Dimension0.60" x 1.80" x 10.60"
- Weight3 oz.
- FeaturesConnect a 4K HDMI monitor to your MacBook Pro or Windows lap
- 4K 30 Hz HDMI output for crisp external displays
- Gigabit Ethernet port provides stable wired networking
- Three USB 3.0 ports (two Type-A, one Type-C) for peripherals
- Built-in SD/SDHC/SDXC card reader for quick media access
- 60 W USB-C Power Delivery 3.0 pass-through charges laptop while docked
USB-C multiport adapter with 4K HDMI
Connect a 4K HDMI monitor to a laptop using the USB-C port. The adapter provides two USB-A ports, one USB-C data port, an SD card reader and a Gigabit Ethernet jack. It draws power from the host laptop's USB-C power adapter to run the dock and charge the system.
4K output limited to 30 Hz refresh
The HDMI port supports 4K resolution at 30 Hz, which suits office work and video playback but not high-refresh gaming or fast motion editing. USB 3.0 ports operate at 5 Gbps, so large file transfers take longer than on 10 Gbps or Thunderbolt connections. Gigabit Ethernet tops out at 1 Gbps wired throughput.
60 W Power Delivery 3.0 pass-through
The USB-C PD 3.0 input accepts up to 60 W, reserving 12 W for the dock and delivering up to 48 W to the laptop. Systems that need more than 48 W for charging under load will not receive full power from this adapter. Fast Role Swap prevents device drop-outs when the power cable is connected or removed.
Highlights
- 4K 30 Hz HDMI output for crisp external displays
- Gigabit Ethernet port provides stable wired networking
- Three USB 3.0 ports (two Type-A, one Type-C) for peripherals
- Built-in SD/SDHC/SDXC card reader for quick media access
- 60 W USB-C Power Delivery 3.0 pass-through charges laptop while docked
Specifications
| Brand | StarTech.com |
|---|---|
| Model | DKT30CSDHPD3 |
| Color | Space Gray |
| Compatibility | OS Compatibility Windows 7, 8, 8.1, 10 Mac OS 10.11 to 10.13 Chrome OS |
| Ports Spec | 1 x USB Type-C (24 pin) USB 3.0 Male 1 x HDMI (19 pin) Female 1 x RJ-45 Female 2 x USB Type-A (9 pin) USB 3.0 Female 1 x SD Slot Female 1 x USB Type-C (24 pin) USB 3.0 Female |
| Dimension | 0.60" x 1.80" x 10.60" |
| Weight | 3 oz. |
| Features | Connect a 4K HDMI monitor to your MacBook Pro or Windows laptop with this USB-C HDMI multiport adapter Utilize USB devices when you travel with 3 x USB 3.0 ports - 2 x USB-A and 1 x USB-C Power both the multiport adapter and your laptop, using your laptop's USB-C power adapter (supports USB Power Delivery 3.0) Get easy access to your SD, SDHC and SDXC memory cards, or microSD cards (with adapter) Add wired network connectivity with the Gigabit Ethernet RJ45 port |
| Shipping weight | 0.20 kg |
| Package size | 165 × 142 × 33 mm |
Questions about this item
Should I pick the 30 Hz or 60 Hz HDMI option?
The adapter outputs 4K at 30 Hz over HDMI; no 60 Hz version is offered.
Will the 4K 30 Hz output feel sluggish on my MacBook Pro?
30 Hz is fine for office apps and video playback, but fast motion or gaming will show visible judder.
What does the USB-C PD 3.0 pass-through actually deliver to my laptop?
It passes up to 60 W total, supplying 48 W to the laptop and reserving 12 W for the dock itself.
