Sta-Kon RB14-10 Ring Terminal #10 Stud 14 AWG 600V Nylon Insulated

Ring Terminal for #10 Stud

The Sta-Kon RB14-10 is a nylon-insulated ring terminal built for 14 AWG copper conductors. It accepts wires from 18 AWG up to 14 AWG and carries a 600 V rating with UL and CSA certifications. The blue partial-coverage insulation identifies the wire range at a glance. It suits automotive, marine and industrial wiring jobs that require a secure #10 stud connection.

Crimp-On Replacement for Loose Lugs

This terminal replaces worn or undersized lugs on existing 14 AWG leads. The serrated barrel bites the copper when crimped, eliminating the intermittent contact that plagues set-screw or solder-only joints. The jump is worth it when vibration or thermal cycling has loosened factory terminals and a permanent crimped joint is required. Tin-plated copper resists corrosion in damp environments.

Stable Contact Under Continuous Load

The tin-plated copper barrel maintains low resistance at the maximum 221 °F operating temperature. Serrations distribute clamping force evenly across the strands, preventing hot spots during sustained current flow. The nylon insulation retains dielectric strength without cracking when the lug heats and cools repeatedly. The 0.31 in tongue width keeps the bolted joint mechanically stable over long service intervals.
