Grey steel enclosed safety switch, surface mount, 60 amp 3PST 240V 15hp

SQUARE D

SQUARE D Safety Switch 60 A 3PST 240 V 15 hp

SKU CH-K8TP-E0MAE

A 60 A, 240 V safety switch with three poles and 15 hp rating for indoor surface mounting

  • TypeLight Switch
  • 60 A rating supports heavy-duty 240 V circuits
  • 15 hp motor capacity handles demanding industrial loads
  • Three-pole single-throw design isolates all phases simultaneously
  • NEMA 1 steel enclosure protects contacts in indoor environments
  • IP20 rating guards against solid object ingress

Safety Switch 60 A 240 V 15 hp

This enclosed safety switch carries a 60 A current rating at 240 V AC and delivers 15 hp motor capacity. It uses a 3PST contact form and includes a neutral assembly for three-phase loads. The steel housing is rated NEMA 1 and IP20 for indoor surface-mount installation. It accepts Class H, K and R fuses with an optional Class R fuse kit.

Capacity and headroom

The 60 A rating handles standard motor loads up to 15 hp at 240 V AC with adequate headroom for inrush current. It runs out when the connected load exceeds the 60 A continuous rating or the 15 hp nameplate limit. The standard-duty enclosure and IP20 rating restrict use to clean indoor environments only.

Fuse class compatibility

This switch is designed for Class H, Class K and Class R fuses and ships with a neutral assembly included. A separate Class R fuse kit (RFK03H) is required for Class R fuse rejection feature. Buyers needing a different fuse class or an outdoor-rated enclosure cannot use this model.

Highlights

  • 60 A rating supports heavy-duty 240 V circuits
  • 15 hp motor capacity handles demanding industrial loads
  • Three-pole single-throw design isolates all phases simultaneously
  • NEMA 1 steel enclosure protects contacts in indoor environments
  • IP20 rating guards against solid object ingress

Specifications

BrandSquare D
TypeLight Switch

Questions about this item

Will the 60 A rating handle my existing 240 V motor load?

The switch is rated for 60 A and 15 hp at 240 V AC, so it will carry the same current your motor draws up to that limit.

How can I verify the 3PST contacts are operating correctly after wiring?

With power off, use a continuity tester across each pole; all three should close cleanly when the handle is moved to ON and open fully on OFF.

Does the enclosure include the Class R fuse kit or must I order it separately?

The steel NEMA 1 enclosure ships with the neutral assembly installed; the Class R fuse kit (RFK03H) is a separate accessory.
