Square D plug-in limit switch, side rotary actuator, miniature body, NEMA rated

SQUARE D

SQUARE D Plug-In Limit Switch Side Rotary Actuator 10A 600V 2NC/2NO NEMA 1/12/13/2/4/6/6P

SKU CH-4ET1-QDES4

Plug-in limit switch with side rotary actuator rated 10 A at 600 V, 2NC/2NO contacts, NEMA 1/2/4/6/6P/12/13 protection, 2.5 in high, .83 in wide, 1.14 in deep

  • TypeLight Switch
  • Side rotary actuator enables precise position sensing
  • 10 A at 600 V AC and DC handles demanding control circuits
  • 2 NC and 2 NO contacts provide flexible wiring options
  • NEMA 1, 2, 4, 6, 6P, 12, 13 ratings suit harsh indoor and outdoor environments
  • Miniature body measuring 2.5 in high, .83 in wide, 1.14 in deep fits tight mounting spaces

Plug-In Limit Switch for Industrial Use

This plug-in limit switch uses a side-mounted rotary actuator to detect mechanical position in automated equipment. It carries a 10 A rating at 600 V for both AC and DC circuits with a 2NC/2NO contact arrangement. The miniature body measures 2.5 in high, 0.83 in wide and 1.14 in deep for surface mounting in tight enclosures.

NEMA 1, 12, 13, 2, 4, 6, 6P Environmental Rating

The switch housing meets NEMA types 1, 2, 4, 6, 6P, 12 and 13, providing protection against dust, water ingress, oil and temporary submersion. It is not boot-sealed at the actuator, so the shaft opening relies on the enclosure rating rather than a dedicated shaft seal. The plug-in base allows quick replacement without rewiring the terminal block.

10 A 600 V Contact Capacity and Headroom

The 2NC/2NO contacts handle up to 10 A at 600 V on resistive loads, giving ample margin for typical control-circuit pilot duties such as relay coils, solenoids or PLC inputs. The rating does not extend to high-inrush motor loads or inductive switching beyond the stated values, so applications with heavy contactor coils may need an interposing relay. The miniature frame limits available wiring space behind the switch.

Highlights

  • Side rotary actuator enables precise position sensing
  • 10 A at 600 V AC and DC handles demanding control circuits
  • 2 NC and 2 NO contacts provide flexible wiring options
  • NEMA 1, 2, 4, 6, 6P, 12, 13 ratings suit harsh indoor and outdoor environments
  • Miniature body measuring 2.5 in high, .83 in wide, 1.14 in deep fits tight mounting spaces

Specifications

BrandSquare D
TypeLight Switch

Questions about this item

Should I pick the 2NC/2NO contact form or a different configuration?

The switch provides two normally closed and two normally open contacts, giving four independent circuits for position sensing or safety interlocks.

What does the 10 A 600 V rating mean when the switch is installed?

Each contact can carry up to 10 amps at 600 volts AC or DC, so the device suits heavy-duty motor controls and industrial power circuits.

Which NEMA ratings apply and what environments do they cover?

Ratings 1, 2, 4, 6, 6P, 12 and 13 protect against dust, water, oil and temporary submersion in indoor and outdoor installations.
