Square D 9013FY pressure switch, compact grey enclosure with single port and adjustment knobs

SQUARE D

SQUARE D 9013FY Pressure Switch 50-70PSI 1Port 10A

SKU CH-DJ4W-JWF9R

A DPST pressure switch for water pumps, factory set at 50/70 psi with a 20 to 30 psi differential and a 10 A rating

  • TypeLight Switch
  • Standard pressure control for water-pump systems with 50-70 psi factory settings
  • Handles up to 10 A for reliable motor switching across single- and three-phase circuits
  • NEMA 1 enclosure suits indoor installations without extra weather protection
  • DPST contact form breaks both lines for safer pump shutdown
  • Wide 5-80 psi adjustable range lets you match specific tank requirements

Pressure Switch 9013FY 50-70PSI

The Square D 9013FY is a pressure switch designed to control water pump systems automatically. It monitors system pressure and activates the pump motor when pressure drops to the cut-in point, stopping it again at the cut-out point. This unit suits residential, agricultural, or light commercial installations where reliable pressure regulation is required. The DPST contact form handles both legs of the supply circuit for safer switching.

Upgrade from manual or fixed-range switches

This switch replaces manual pump controls or older switches with non-adjustable ranges that cannot match the 50 to 70 psi factory setting. The jump is worth it when the system demands a 20 to 30 psi differential and a broader 5 to 80 psi adjustable range for fine-tuning. It supports motors up to 2 hp at 120 V single-phase, 3 hp at 240 V single-phase, and 5 hp at 240 V three-phase, covering larger pumps that smaller switches cannot carry.

Sustained load behaviour

Under continuous cycling the DPST contacts maintain stable operation across the full 5 to 80 psi range without unloader assistance. The NEMA 1 enclosure protects the mechanism in indoor or sheltered locations during extended duty cycles. Rated for 10 A, the switch handles the inrush and running current of compatible motors repeatedly, while the standard action ensures consistent cut-in and cut-out performance over time.

Highlights

  • Standard pressure control for water-pump systems with 50-70 psi factory settings
  • Handles up to 10 A for reliable motor switching across single- and three-phase circuits
  • NEMA 1 enclosure suits indoor installations without extra weather protection
  • DPST contact form breaks both lines for safer pump shutdown
  • Wide 5-80 psi adjustable range lets you match specific tank requirements

Specifications

BrandSquare D
TypeLight Switch

Questions about this item

What size pipe thread does the 1/4 in FNPS port on the 9013FY pressure switch accept?

The switch has a single 1/4 inch female NPS port for direct connection to the water pump line.

Which wiring step is most often missed when installing the DPST contacts on this 9013FY switch?

Both poles of the DPST contact set must be wired; leaving one pole open will prevent the motor from starting.

How often should the pressure differential setting of 20 to 30 psi be checked on the 9013FY switch?

Verify the 20 to 30 psi differential annually or whenever the pump cycles irregularly to maintain the 50/70 psi factory range.
