SQUARE D
SQUARE D 9013FH Pressure Switch 60-80PSI 1Port DPST 10A
Controls air-compressor pressure from 60 to 80 psi with a DPST 10 A contact rated for 1½ hp at 120 V and 2 hp at 240 V single-phase
- TypeLight Switch
- Color/FinishBlue
- Factory-set 60-80 psi cut-in/cut-out for consistent compressor cycling
- DPST contacts handle 10 A at 120-480 V for single and three-phase motors
- Single 1/4 in MNPT port simplifies tank mounting
- NEMA 1 enclosure rated from -22 °F to 257 °F for harsh environments
- 20 psi differential across 20-100 psi range suits varied pressure demands
Pressure Switch 60-80 psi Range
The Square D 9013FH pressure switch controls air compressor cycles between 60 and 80 psi with a 20 psi differential. It is built for installers and maintenance technicians who need reliable on-off control for single-phase or three-phase motors.
1/4 in MNPT Port DPST Contacts
The single 1/4 inch MNPT port threads directly into the compressor tank or manifold without adapters. DPST electrical contacts switch both lines for 10 A loads, and the NEMA 1 enclosure suits indoor mounting on a wall or machine frame.
Check Motor Voltage and Phase Rating
Verify that the motor voltage and phase match the horsepower ratings listed for 120 V, 240 V or 480 V operation. Confirm the ambient temperature stays within the -22 to 257 degrees F range and that the 60-80 psi factory setting suits your system pressure requirements.
Highlights
- Factory-set 60-80 psi cut-in/cut-out for consistent compressor cycling
- DPST contacts handle 10 A at 120-480 V for single and three-phase motors
- Single 1/4 in MNPT port simplifies tank mounting
- NEMA 1 enclosure rated from -22 °F to 257 °F for harsh environments
- 20 psi differential across 20-100 psi range suits varied pressure demands
Specifications
| Brand | Square D |
|---|---|
| Type | Light Switch |
| Color/Finish | Blue |
Questions about this item
What pressure range does the 9013FH switch cover and what is its differential?
The switch covers a 20 to 100 psi range with a 20 psi differential, factory set to turn on at 60 psi and off at 80 psi.
What port size and thread type does this pressure switch use for mounting?
It has a single 1/4 in MNPT port for direct connection to the air compressor tank or line.
How is the 9013FH wired and what common mistake should be avoided?
Wire the DPST contacts to break both lines of the motor circuit; a common error is switching only one leg on 240 V single-phase units.
