SQUARE D
SQUARE D 9013FH Pressure Switch 120-150PSI 1Port Unload
Pressure switch for air compressors with a 120-150 psi on/off setting and 30 psi differential
- TypeLight Switch
- Factory-set 120/150 psi range for immediate air-compressor control
- 30 psi differential keeps motor cycling smooth and efficient
- DPST contacts handle 1.5 hp at 120 V and 2 hp at 240 V single-phase
- Single 1/4 in FNPS port simplifies plumbing on standard compressor tanks
- NEMA 1 enclosure rated for indoor workshop environments
Pressure Switch 120-150 PSI
This Square D 9013FH pressure switch controls air compressor operation between 120 and 150 PSI. It features a 30 PSI differential and a factory-set on/off range. The unit uses a DPST contact form and carries a NEMA 1 rating. It is designed for standard action in compressed air systems.
Single Port 1/4 Inch Connection
The switch installs via a single 1/4 inch FNPS port. An integrated unloader valve releases head pressure on shutdown, reducing motor restart load. It supports up to 1.5 hp at 120V single phase and 2 hp at 240V single phase. Three-phase ratings reach 3 hp at 240V and 1 hp at 480V.
For Air Compressor Replacement
This component suits technicians replacing a failed pressure control on compatible air compressors. Buyers needing a different pressure range or multiple ports should look elsewhere. It is not a general-purpose light switch despite the catalog classification.
Highlights
- Factory-set 120/150 psi range for immediate air-compressor control
- 30 psi differential keeps motor cycling smooth and efficient
- DPST contacts handle 1.5 hp at 120 V and 2 hp at 240 V single-phase
- Single 1/4 in FNPS port simplifies plumbing on standard compressor tanks
- NEMA 1 enclosure rated for indoor workshop environments
Specifications
| Brand | Square D |
|---|---|
| Type | Light Switch |
Questions about this item
How much does the 30 psi differential affect cut-in pressure when the compressor runs continuously?
The 30 psi differential means the switch cuts in at 120 psi and cuts out at 150 psi; sustained operation keeps cycling within this fixed 30 psi band.
What heat or noise should I expect from the NEMA 1 enclosure during all-day duty?
The NEMA 1 enclosure is rated for indoor use only and has no integrated cooling; heat and audible click come from the DPST contacts cycling at the 30 psi differential.
Which circuit breaker and wire gauge must I already have for the 2 hp 240 V single-phase rating?
A 240 V supply protected by a double-pole breaker and conductors sized for 2 hp single-phase motor load are required; the switch provides DPST contacts rated for that duty.
