SQUARE D 8501KUDR13V53 relay socket 10 A 24 V DC 11 pin
11-pin relay socket accepts 10 A at 24 V DC with quick-connect flat pins and mechanical flag indicator
- Square base fits standard 11-pin panel cutouts
- 10 A at 240 V AC handles motor and heater loads
- 12 A at 28 V DC suits mobile and battery systems
- Mechanical flag shows relay status without extra wiring
- Quick-connect flat pins speed up installation and maintenance
Square 11-pin relay socket
This Schneider Electric 8501KUDR13V53 socket accepts a general-purpose relay with a square base and eleven flat pins. It is rated for 10 amperes at 240 volts AC and 12 amperes at 28 volts DC. The coil operates on 24 volts DC. A mechanical flag provides a visual status indicator.
For control panels needing quick-connect wiring
The quick-connect terminals and enclosed body suit panel builders who want fast, tool-free installation. The 0.189-inch flat pins match standard 11-pin relays. Buyers who need a push-to-test button or a different pin count should look at other socket styles.
The 11 flat pins and 24 V DC coil voltage decide fit
Only relays with exactly eleven 0.189-inch flat pins and a 24 V DC coil will seat and operate correctly in this socket. Verify the relay's pin layout and coil specification before ordering.
Highlights
- Square base fits standard 11-pin panel cutouts
- 10 A at 240 V AC handles motor and heater loads
- 12 A at 28 V DC suits mobile and battery systems
- Mechanical flag shows relay status without extra wiring
- Quick-connect flat pins speed up installation and maintenance
Specifications
| Brand | SCHNEIDER ELECTRIC |
|---|
Questions about this item
Which relay coil voltage must my control circuit supply for the 8501KUDR13V53 socket?
The socket is rated for a 24 V DC coil, so your control circuit must provide 24 V DC to operate the relay correctly.
Can I use this 11-pin socket with an older 8-pin relay I already have?
No, the socket has 11 flat pins spaced for an 11-pin relay; an 8-pin relay will not align or make proper contact.
How do I confirm the relay is switching after I wire the socket?
The mechanical flag indicator on the relay body moves visibly when the coil energises, showing the contacts have changed state.
