SQUARE D 8501KPR13P14V14 24V AC 10A 11-pin relay socket
An 11-pin octal relay socket rated for 10 A at 24 V AC with an LED status indicator
- 11-pin octal base fits standard relay sockets
- 10 A rating handles 277 V AC and 28 V DC loads
- 24 V AC coil voltage suits common control circuits
- Built-in LED indicator shows relay status at a glance
- Enclosed body with mechanical flag protects contacts in harsh environments
Octal-base relay socket for 24 V AC control circuits
This 11-pin octal socket accepts a general-purpose relay rated for 10 A at 277 V AC or 28 V DC. It is suited for panel builders and maintenance teams wiring motor-starter or lighting-control panels that use 24 V AC coil voltage. The enclosed body and LED status indicator simplify troubleshooting in industrial cabinets.
10 A contact rating with 1/3 hp at 120 V AC
The socket carries the relay’s full 10 A resistive load and handles fractional-horsepower motor loads up to 1/3 hp on 120 V AC or 1/2 hp on 240 V AC. It is not intended for higher horsepower motors or loads exceeding the 10 A rating, so larger contactors are required beyond those limits.
Enclosed housing with LED indicator runs cool
The sealed enclosure protects contacts from dust and moisture while the built-in LED gives immediate coil-status visibility. No push-to-test button is fitted, so functional checks rely on the indicator or external test equipment. Power draw is limited to the 24 V AC coil consumption of the installed relay.
Highlights
- 11-pin octal base fits standard relay sockets
- 10 A rating handles 277 V AC and 28 V DC loads
- 24 V AC coil voltage suits common control circuits
- Built-in LED indicator shows relay status at a glance
- Enclosed body with mechanical flag protects contacts in harsh environments
Specifications
| Brand | SCHNEIDER ELECTRIC |
|---|
Questions about this item
Will the 11-pin octal socket accept my existing 24 V AC relay with an 11-pin base?
Yes, the socket is designed for an 11-pin octal base and a 24 V AC coil voltage, so a matching relay will plug in directly.
How can I confirm the socket is powered and the relay contacts are switching?
The built-in LED indicator lights when the 24 V AC coil is energised, and the mechanical flag moves to show contact position.
Does the package include a hold-down clip or mounting hardware for DIN-rail installation?
The product is supplied as the socket only; clips, brackets or DIN-rail adapters must be purchased separately.
