Gray CPVC Schedule 80 trap with brass female connector

Spears

Spears 835-015CBR 1-1/2 in CPVC Schedule 80 trap

SKU CH-D1K6-KE0KT MPN 835-015CBR

CPVC Schedule 80 female connector joins 1-1/2 inch FNPT threads to socket fittings for 140°F maximum service

  • TypeDrain Components
  • ColorGray
  • Schedule 80 CPVC handles 140 °F continuous service
  • FNPT × socket ends join threaded and solvent-weld pipe
  • ASTM D1784 material meets code for hot-water drains
  • Gray finish identifies CPVC at a glance
  • Spears 835-015CBR model fits 1-1/2 in piping systems

CPVC Schedule 80 Female Connector

This Spears 835-015CBR fitting joins a 1-1/2 inch FNPT thread to a socket connection in CPVC piping systems. The Schedule 80 wall thickness handles higher pressure ratings than standard Schedule 40 components. Gray CPVC construction meets ASTM D1784 material standards for chemical resistance and durability. Maximum operating temperature is rated at 140 degrees Fahrenheit.

Suitable for hot and cold water distribution

Plumbers and maintenance crews use this connector to transition between threaded and solvent-weld joints in industrial or commercial CPVC installations. It is not intended for systems exceeding the 140 degree Fahrenheit temperature limit or for pipe sizes other than 1-1/2 inch. Buyers needing a different connection type or material should select an alternative fitting.

Schedule 80 pressure rating

The Schedule 80 designation confirms this connector withstands the elevated working pressures required in demanding CPVC applications. Verify that your system design matches this pressure class and the 1-1/2 inch nominal size before ordering.

Highlights

  • Schedule 80 CPVC handles 140 °F continuous service
  • FNPT × socket ends join threaded and solvent-weld pipe
  • ASTM D1784 material meets code for hot-water drains
  • Gray finish identifies CPVC at a glance
  • Spears 835-015CBR model fits 1-1/2 in piping systems

Specifications

TypeDrain Components
ColorGray
BrandSpears
Model835-015CBR

Questions about this item

What size CPVC pipe and schedule rating must I already have for the 835-015CBR socket end to fit?

The socket end fits 1-1/2 in CPVC pipe manufactured to Schedule 80 dimensions.

Will the FNPT threads on this connector mate with the brass fittings already on my 140 Degrees F hot-water lines?

Yes, the FNPT threads follow standard taper dimensions so they will engage existing brass fittings rated for the same temperature.

After assembly, how can I confirm the joint meets the ASTM D1784 material standard?

Verify the gray CPVC body carries the ASTM D1784 marking and pressure-test the completed joint for leaks at operating temperature.
