Compact white desktop firewall appliance with front status LEDs and rear port array

SonicWall

SonicWall TZ470W 02SSC6801 firewall appliance

SKU CH-W8TB-J28ND MPN 02SSC6801

Wireless desktop firewall with 8 Gigabit and 2 2.5 Gigabit ports, 150 site-to-site VPN tunnels, and Deep Packet Inspection security services included for one year

  • TypeWireless
  • Form FactorDesktop
  • StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHC
  • ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
  • SecuritySecurity Services Deep Packet Inspection services: Gateway A
  • Ports8x1GbE, 2x2.5GbE, 2 USB 3.0, 1 Console
  • Advanced threat protection via Deep Packet Inspection SSL and Gateway Anti-Virus
  • 150 site-to-site VPN tunnels for secure multi-site connectivity
  • 5 GbE and 1 GbE ports for high-speed wired throughput
  • FIPS 140-2 Level 2 certified encryption for regulated environments
  • Desktop form factor with 21.98 W max power consumption

SonicWall TZ470W Wireless Firewall

The SonicWall TZ470W is a desktop next-generation firewall with integrated wireless. It includes a 1-year Advanced Protection Security Suite for automated breach detection and prevention. The appliance targets small organisations and distributed enterprises with SD-Branch locations. Zero-Touch Deployment simplifies rollout across multiple sites.

Suited for encrypted traffic inspection

This unit suits teams needing deep packet inspection of SSL traffic and up to 150 site-to-site VPN tunnels. It also supports 200 IPsec clients and 150 SSL VPN licenses. Buyers requiring more than two 2.5 GbE ports or redundant power supplies should evaluate other models. The fixed desktop form factor does not fit standard rack mounts.

256 GB expandable storage for logs and caching

Internal storage can be expanded to 256 GB to handle logging, reporting, caching and firmware backup. Eight 1 GbE and two 2.5 GbE ports provide connectivity headroom for typical branch traffic. Maximum power draw is 21.98 W from a 100-240 VAC supply. The compact chassis measures 3.5 x 13.5 x 19 cm and weighs 0.87 kg.

Highlights

  • Advanced threat protection via Deep Packet Inspection SSL and Gateway Anti-Virus
  • 150 site-to-site VPN tunnels for secure multi-site connectivity
  • 5 GbE and 1 GbE ports for high-speed wired throughput
  • FIPS 140-2 Level 2 certified encryption for regulated environments
  • Desktop form factor with 21.98 W max power consumption

Specifications

BrandSONICWALL
SeriesTZ 470W
ModelTZ 470W - Total Secure (1Y APSS)
Part Number02-SSC-6801
TypeWireless
Form FactorDesktop
StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
SecuritySecurity Services
Deep Packet Inspection services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS): HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service
Application Visualization
Application Control
Capture Advanced Threat Protection
Ports8x1GbE, 2x2.5GbE, 2 USB 3.0,
1 Console
VPNSite-to-site VPN tunnels: 150
IPSec VPN clients (maximum:) 5 (200)
SSL VPN licenses (maximum): 2 (150)
Encryption/authentication: DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange: Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN: RIP, OSPF, BGP
Certificate support: Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP
VPN features: Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported: Microsoft®, Windows 10
NetExtender: Mi
CertificationsFIPS 140-2 Level 2 (with Suite B), IPv6/USGv6, ICSA Network Firewall, ICSA Firewall Enterprise, ISCA Network Antivirus / AntiMalware
ComplianceFCC Class B, FCC RF ICES Class B, IC RF CE (R&TTE, EMC, LVD, RoHS), RCM, VCCI Class B, MIC/TELEC, UL, cUL, CB, Mexico CoC by UL, WEEE, REACH, ANATEL
Power Input100 - 240 VAC,
50-60 Hz, 3A
Max Power Consumption21.98W
Dimensions3.5x13.5x19 (cm)
1.8x5.3x7.5 (in)
Weight0.87 kg / 1.92 lbs
Shipping weight1.81 kg
Package size229 × 229 × 76 mm

Questions about this item

What internet connection or uplink do I need to use the 2.5 GbE ports on the TZ470W?

The 2.5 GbE ports require an ISP link or upstream switch that also runs at 2.5 Gbps; they will fall back to 1 Gbps if the far end only supports Gigabit.

Can I keep my existing 1 GbE access points and switches when I deploy this firewall?

Yes, the eight 1 GbE ports and two 2.5 GbE ports auto-negotiate down to 1 Gbps, so legacy 1 GbE gear works without configuration changes.

Which LED or dashboard indicator confirms the Total Secure suite is active after I register the appliance?

In the SonicWall management UI the Licenses > Security Services page shows green check marks for Gateway Anti-Virus, Anti-Spyware, IPS, DPI-SSL and Content Filtering when the 1-year Advanced Protection Security Suite is enabled.
