Snapconnect SNAP1221PLW Pilot Lit Wall Switch 20 A 120/277V AC
A 20 A single-pole toggle switch with a built-in pilot light, rated for 120/277 V AC and back-wired modular connections in a white impact-resistant thermoplastic housing
- Pilot light shows circuit status at a glance
- 20 A rating handles heavy-duty loads reliably
- 120/277 V AC suits residential and commercial wiring
- Modular wiring connection speeds up installation time
- UL Listed and impact-resistant thermoplastic ensures durability
Snapconnect Pilot Lit Wall Switch 20 A
The Snapconnect SNAP1221PLW is a single-pole toggle switch rated at 20 A for 120/277V AC circuits. It includes an integrated pilot light for clear status indication in industrial and commercial environments. The thermoplastic housing provides impact resistance and is UL Listed for safety compliance.
20 A Current Rating Determines Circuit Fit
The 20 A current rating is the primary specification that decides whether this switch matches the protected circuit. It supports a 2 hp motor load and uses modular back-wiring for secure termination. Installers must verify the branch circuit breaker does not exceed this ampere rating.
Thermal Performance at 167 °F Maximum
The switch is rated for a maximum operating temperature of 167 °F, indicating its capacity to handle sustained load without degradation. The impact-resistant thermoplastic housing maintains structural integrity under continuous thermal cycling. This makes it suitable for demanding industrial applications where ambient temperatures remain elevated.
Highlights
- Pilot light shows circuit status at a glance
- 20 A rating handles heavy-duty loads reliably
- 120/277 V AC suits residential and commercial wiring
- Modular wiring connection speeds up installation time
- UL Listed and impact-resistant thermoplastic ensures durability
Specifications
| Brand | HUBBELL |
|---|
Questions about this item
What does the 20 A rating mean when the switch is installed in a circuit?
The switch is rated to carry up to 20 amperes continuously on a 120/277 V AC circuit, suitable for loads up to 2 hp.
How does the modular wiring connection work and what does it limit?
The back-wired modular connector accepts pre-terminated leads for quick installation and is limited to the switch’s 20 A, 120/277 V AC rating.
What wall-box depth and mounting style does this toggle switch require?
It fits a standard single-gang box, mounts with two screws, and the thermoplastic body is impact-resistant for industrial use.
