SMA
SMA 8K HDMI + DP KVM Switch 2×2 4 USB 3.0 Desktop Controller
Share one keyboard, mouse, two monitors and four USB 3.0 devices between two computers at up to 8K@60Hz with push-button or desktop-controller switching
- Type2 Port HDMI + Displayport
- PC ConnectorsHDMI + Displayport
- Computer Connections2 Ports
- Monitor Connections2 Ports
- Video ResolutionEnjoy breathtaking, crystal-clear visuals with support for u
- PC SelectionPush Buttons and Desktop COntroller
- Control two computers with one keyboard and mouse
- View ultra-sharp 8K visuals at 60Hz on dual monitors
- Transfer files at 5Gbps through four USB 3.0 ports
- Switch instantly via front button or desktop controller
- Stable 12V power keeps signals solid all day
Dual 8K KVM Switch
This SMA KVM switch lets you control two computers from one keyboard, mouse and dual-monitor setup. It accepts one HDMI and one DisplayPort input per computer and drives one HDMI and one DisplayPort monitor at up to 8K 60 Hz. Four USB 3.0 ports (three Type-A, one Type-C) share peripherals at 5 Gbps. A 12 V power adapter and desktop controller are included for stable operation.
Suits dual-display workstations
It fits users who need to switch two PCs or a PC and a laptop across two native HDMI and DP monitors without converter cables. Extended and copy modes work only when both hosts support dual outputs. Buyers whose machines lack both an HDMI and a DP port, or who want to mix HDMI-only and DP-only displays, should look at a different switch.
8K 60 Hz over HDMI 2.1 and DP 2.0
The decisive specification is the video interface: each computer must provide one HDMI 2.1 and one DisplayPort 2.0 connection to reach 8K 60 Hz. Lower resolutions such as 4K 120 Hz or 1080p 240 Hz are also supported, but the host must still output both signal types natively.
Highlights
- Control two computers with one keyboard and mouse
- View ultra-sharp 8K visuals at 60Hz on dual monitors
- Transfer files at 5Gbps through four USB 3.0 ports
- Switch instantly via front button or desktop controller
- Stable 12V power keeps signals solid all day
Specifications
| Model | 8K HDMI + DP |
|---|---|
| Type | 2 Port HDMI + Displayport |
| PC Connectors | HDMI + Displayport |
| Computer Connections | 2 Ports |
| Monitor Connections | 2 Ports |
| Video Resolution | Enjoy breathtaking, crystal-clear visuals with support for ultra-high resolution up to 8K@60Hz. This KVM switch DisplayPort HDMI combo delivers flawless, lag-free transmission for gaming, design, and video editing. Fully backward compatible with 4K@120Hz/60Hz, 1080p, and more. |
| PC Selection | Push Buttons and Desktop COntroller |
| Monitors Supported | HDMI, DP |
| LED Indicators | Yes |
| Power Features | Come with DC 12V Power Adapter |
| USB Features | This HDMI display port KVM switch dual monitor is equipped with 4 USB Ports(3 USB 3.0 Ports & 1 USB-C Ports) , 3 USB 3.0 Ports and USB C port can reach a maximum data transfer rate of 5Gbps, which is 10 times faster than USB 2.0 ports. |
| Application | The dual HDMI Displayport KVM switch 2 monitors 2 computers allows you to control 2 computers with just one set of keyboard and mouse, and sharing not only two HD monitors & 4 USB devices, This dual display KVM switch 2 ports support Extended & Copy Mode (only available on hosts that support dual display). Meet your need to switch freely between work computers and personal computers. |
| Features | It supports various systems such as Windows/Vista/XP and Mac OS, Linux and Unix, and is plug and play. |
| Dimensions | 150x65x35mm |
| Package Contents | 1 x HDMI DP KVM USB Switch 2x2 2 x USB 3.0 data cable 1 x 5V DC power adapter 1 x External switch kit 1 x User Manual |
Questions about this item
Does each computer need both an HDMI and a DisplayPort output to use this KVM switch?
Yes, each computer must provide one HDMI and one DisplayPort connection; the supplier states that conversion cables between the two are not supported.
Will the switch pass through 4K at 120 Hz from an older graphics card that only has HDMI 2.0?
The unit is backward compatible with 4K@120Hz, so a source limited to HDMI 2.0 can still deliver that refresh rate over the HDMI path.
How can I confirm the KVM is actively driving both monitors in extended mode after I connect everything?
Both monitor LEDs on the switch will be lit, the desktop controller shows the active PC, and each connected computer detects two separate displays in its display settings.
