Satin chrome electronic pushbutton door lock with lever handle and key override

Simplex

Simplex E5031XKWL-26D door lock, Satin Chrome, Kaba 90 keyway

SKU CH-537H-JVD41 MPN E5031XKWL-26D

An electronic pushbutton lock storing up to 100 access codes with key override for Kaba 90 cylinders and a Grade 1 fire-rated cylindrical latch

  • FinishSatin Chrome
  • Selling UnitBox
  • Backset2-3/4"
  • KeyingKeyed Different
  • Keyless entry with up to 100 access codes
  • Satin Chrome finish resists wear and corrosion
  • ANSI/BHMA Grade 1 certified for heavy-duty use
  • 3-hour UL/ULC fire rating for A-label doors
  • Key override compatible with Kaba 90 keyway cylinders

Electronic pushbutton lock with 100 codes

The Simplex E5031XKWL-26D is a Grade 1 cylindrical lock that stores up to 100 access codes for keyless entry. It suits commercial doors where managing physical keys is impractical. Programming is done at the keypad or through optional Excel-based software. The satin chrome finish resists wear in high-traffic indoor and outdoor settings.

Check door thickness and cylinder compatibility

Verify the door is between 1-3/8" and 2-1/4" thick to match the 2-3/4" backset. The key override requires a K-I-L Kaba cylinder with a Kaba 90 keyway; other cylinders will not fit. No wiring is needed through the door, so existing prep without power transfer is acceptable. Confirm the lock is keyed different if multiple units are ordered.

Heavy-duty cast housing with fire-rated latch

The solid cast housing and levers are built for extensive use and meet ANSI/BHMA A156.2 Grade 1 standards. A 1/2" throw latch with floating faceplate provides reliable latching. The lock carries a 3-hour UL/ULC fire rating for "A" label doors. ADA-compliant levers ensure accessible operation. Battery power keeps the unit running without hardwiring.

Highlights

  • Keyless entry with up to 100 access codes
  • Satin Chrome finish resists wear and corrosion
  • ANSI/BHMA Grade 1 certified for heavy-duty use
  • 3-hour UL/ULC fire rating for A-label doors
  • Key override compatible with Kaba 90 keyway cylinders

Specifications

BrandSimplex
ModelE5031XKWL-26D
FinishSatin Chrome
Selling UnitBox
Backset2-3/4"
KeyingKeyed Different

Questions about this item

Does the Simplex E5031XKWL-26D lock come with a Kaba cylinder or must I supply my own?

The lock is prepared for K-I-L Kaba cylinders with a Kaba 90 keyway; the cylinder itself is not included and must be purchased separately.

How do I decide between the available backset options for this model?

This model is supplied with a fixed 2-3/4" backset; no alternative backset is offered for the E5031XKWL-26D.

What does the ANSI/BHMA A156.2 Grade 1 rating mean for daily use on a commercial door?

Grade 1 certifies the lock for the highest cycle endurance and strength in the standard, making it suitable for heavy-duty commercial traffic.
