Satin chrome electronic pushbutton door lock with lever handle and numeric keypad

Simplex

Simplex E5031SWL-26D Satin Chrome Electronic Pushbutton Door Lock

SKU CH-R1VT-HX66H MPN E5031SWL-26D

Satin-chrome electronic pushbutton lock stores up to 100 codes, offers key override for LFIC Schlage cores, and meets ANSI/BHMA A156.2 Grade 1 with a 3-hour UL fire rating

  • FinishSatin Chrome
  • Selling UnitBox
  • Backset2-3/4"
  • KeyingKeyed Different
  • Electronic keypad stores up to 100 access codes for keyless entry
  • Key override accepts LFIC Schlage cores (5 or 6 pin) for mechanical backup
  • ANSI/BHMA A156.2 Grade 1 certification confirms heavy-duty commercial durability
  • 3-hour UL/ULC fire rating for A-label doors meets safety requirements
  • ADA-compliant levers and 2-3/4" backset fit doors 1-3/8" to 2-1/4" thick

Electronic Pushbutton Access Control

The Simplex E5031SWL-26D is a Satin Chrome electronic pushbutton door lock designed for commercial entry points. It provides exterior access by combination while allowing free egress, storing up to 100 different access codes for flexible user management. Programming is handled via the keypad or optional Microsoft Excel based software, and the lock operates without any wiring to or through the door. It suits facilities needing heavy-duty, keyless access control with a clean finish.

Grade 1 Certified Durability

The lock carries ANSI/BHMA A156.2 Grade 1 certification and a 3-hour UL/ULC fire rating for "A" label doors, confirming its suitability for demanding indoor and outdoor applications. Its solid cast housing and levers resist wear from extensive use, while the cylindrical 1/2" throw latch with floating faceplate ensures reliable operation. ADA-approved levers support accessible entry requirements without compromising structural integrity.

LFIC Schlage Core Compatibility

A key override accepts LFIC Schlage 5 or 6 pin cores, sold separately, allowing integration into existing master key systems. The 2-3/4" backset fits doors 1-3/8" to 2-1/4" thick, simplifying retrofit installations on standard commercial preparations. By removing the need for physical credential issuance and collection, the system frees administrators from ongoing key management overhead while maintaining mechanical backup access.

Highlights

  • Electronic keypad stores up to 100 access codes for keyless entry
  • Key override accepts LFIC Schlage cores (5 or 6 pin) for mechanical backup
  • ANSI/BHMA A156.2 Grade 1 certification confirms heavy-duty commercial durability
  • 3-hour UL/ULC fire rating for A-label doors meets safety requirements
  • ADA-compliant levers and 2-3/4" backset fit doors 1-3/8" to 2-1/4" thick

Specifications

BrandSimplex
ModelE5031SWL-26D
FinishSatin Chrome
Selling UnitBox
Backset2-3/4"
KeyingKeyed Different

Questions about this item

How do I install the E5031SWL-26D on a door with a 2-3/4" backset, and what step is often missed?

Prepare the door for a 2-3/4" backset and 1/2" latch throw. The step often missed is verifying the door thickness is between 1-3/8" and 2-1/4" before drilling, and confirming the floating faceplate aligns with the door bevel.

What maintenance or replacement will the LFIC Schlage core need over time?

The LFIC Schlage core (5 or 6 pin) is sold separately and may need rekeying or replacement if key control is lost. The cylindrical latch assembly is rated for heavy-duty cycles; lubricate the latch bolt periodically per manufacturer guidelines.

What limit appears first during sustained use of the electronic pushbutton lock?

The lock stores up to 100 access codes; that capacity is the first administrative limit reached in high-turnover environments. Mechanically, the Grade 1 cylindrical chassis and 3-hour UL fire rating are tested for extended heavy-duty operation.
