Simplex
Simplex E5031BWL-26D Satin Chrome Electronic Pushbutton Door Lock
Electronic pushbutton lock stores 100 access codes, accepts Best SFIC cores with key override, and meets ANSI/BHMA A156.2 Grade 1 with a three-hour UL fire rating
- FinishSatin Chrome
- Selling UnitBox
- Backset2-3/4"
- KeyingKeyed Different
- Keyless entry with up to 100 programmable codes
- ANSI/BHMA Grade 1 certified for heavy-duty use
- 3-hour UL fire rating for A-label doors
- Key override accepts Best SFIC cores
- Fits doors 1-3/8 to 2-1/4 inches thick
Electronic pushbutton access
The Simplex E5031BWL-26D is a heavy-duty cylindrical lockset with a solid cast housing and levers. It provides keyless entry by combination for up to 100 unique access codes. Programming is handled at the keypad or through optional Excel-based software. No wiring through the door is required.
Commercial Grade 1 security
Suits offices, schools and multi-tenant buildings that need ANSI/BHMA A156.2 Grade 1 durability and a 3-hour UL fire rating for "A" label doors. ADA-compliant levers support accessible egress. Not for buyers who need audit trails, scheduled unlock times or remote management features.
SFIC key override core sold separately
The lock accepts Best and equivalent 6 or 7-pin Small Format Interchangeable Cores, but no core is included in the box. A compatible SFIC must be sourced and installed before the mechanical override function will operate.
Highlights
- Keyless entry with up to 100 programmable codes
- ANSI/BHMA Grade 1 certified for heavy-duty use
- 3-hour UL fire rating for A-label doors
- Key override accepts Best SFIC cores
- Fits doors 1-3/8 to 2-1/4 inches thick
Specifications
| Brand | Simplex |
|---|---|
| Model | E5031BWL-26D |
| Finish | Satin Chrome |
| Selling Unit | Box |
| Backset | 2-3/4" |
| Keying | Keyed Different |
Questions about this item
How many access codes can the E5031BWL-26D store before reaching its limit?
The lock stores up to 100 different access codes for keyless entry management.
Does the cylindrical lockset generate noticeable heat or noise during continuous daily operation?
The mechanical pushbutton design operates without wiring or motors, so it produces no electronic heat or audible noise during use.
Which SFIC core must I already own for the key override to function on this lock?
The key override accepts Best and equivalent 6 or 7 pin length Small Format Interchangeable Cores, sold separately.
