SIEMENS 3UB81234EW2 Overload Relay 10-40A 690V AC 3 Pole
Thermal overload relay protects motors from 10 A to 40 A at up to 690 V AC with selectable trip classes 5, 10, 20 or 30 and direct contactor mounting
- Adjustable protection from 10 A to 40 A
- Four selectable trip classes 5 10 20 30
- Rated for 690 V AC three-phase circuits
- Direct contactor mounting with screw terminals
- Automatic and manual reset options included
Industrial Motor Protection Relay
The SIEMENS 3UB81234EW2 overload relay protects three-phase motors by monitoring current between 10 A and 40 A at up to 690 V AC. It mounts directly to compatible contactors and provides one normally open and one normally closed auxiliary contact for control circuits.
Adjustable Trip Classes For Sustained Operation
Four selectable trip classes — 5, 10, 20 and 30 — let the installer match the relay response to the motor starting profile and continuous duty cycle. This flexibility helps prevent nuisance tripping during long acceleration or frequent start-stop sequences without sacrificing overload protection.
Screw Terminals And Direct Contactor Mounting
The unit uses screw terminals for secure wiring and attaches straight to the contactor, keeping the installation compact and reducing panel wiring. Auto and manual reset modes are both available so the operator can choose the recovery method that suits the application.
Highlights
- Adjustable protection from 10 A to 40 A
- Four selectable trip classes 5 10 20 30
- Rated for 690 V AC three-phase circuits
- Direct contactor mounting with screw terminals
- Automatic and manual reset options included
Specifications
| Brand | SIEMENS |
|---|
