Sick LL3-DV05 fiber-optic proximity cable with threaded M6 head and 90-degree deflection

Sick

Sick LL3-DV05 Proximity system fiber-optic cable

SKU CH-RCGR-GPR0M

A 2 m cuttable PMMA fiber with integrated lens and 90° deflection for GLL170, WLL180T and WLL24 Ex sensors

  • 90° deflection simplifies routing in tight spaces
  • 2 m PMMA fiber suits GLL170, WLL180T and WLL24 Ex sensors
  • Operates from –40 °C to +70 °C for harsh environments
  • M6 threaded sleeve enables secure, tool-free mounting
  • Integrated lens detects objects down to 0.015 mm

Fiber-optic proximity sensor cable

The SICK LL3-DV05 is a 2 m PMMA fiber-optic cable designed for proximity sensing with GLL170(T), WLL180T and WLL24 Ex sensors. Its threaded M6 sleeve with 90° deflection suits tight machine mounts where straight heads cannot fit. The monofiber core detects objects down to 0.015 mm within a 15.94° dispersion angle. Buyers needing longer reach or side-view optics without integrated deflection should look elsewhere.

Industrial temperature rating and bend limits

The cable operates from –40 °C to +70 °C and accepts a minimum bend radius of 25 mm, so it survives routing through cable chains and around sharp corners in cold stores or engine bays. The PE jacket resists abrasion while the PA head withstands mechanical stress at the sensing point. Infrared compatibility at 1450 nm is not supported, limiting use with certain long-wavelength emitters.

Bundled cutter nut and mounting hardware

Delivery includes an M6 hexagon nut for secure panel mounting and the FC fiber cutter (5304141) for clean, on-site length adjustment without adapter sleeves. The cutter ensures a perpendicular end face that preserves the specified dispersion angle and minimal object detection. No tip adapters are required or compatible, simplifying installation for maintenance teams.

Highlights

  • 90° deflection simplifies routing in tight spaces
  • 2 m PMMA fiber suits GLL170, WLL180T and WLL24 Ex sensors
  • Operates from –40 °C to +70 °C for harsh environments
  • M6 threaded sleeve enables secure, tool-free mounting
  • Integrated lens detects objects down to 0.015 mm

Specifications

BrandSICK
ModelSICK LL3-DV05

Questions about this item

How do I install the Sick LL3-DV05 fiber-optic cable with its M6 threaded sleeve and 90° deflection?

Screw the M6 threaded sleeve into the mounting point using the supplied hexagon nut, route the 2 m PMMA fiber with a minimum bend radius of 25 mm, and use the included FC fiber cutter (5304141) to trim the cable end squarely before inserting it into the compatible GLL170(T), WLL180T or WLL24 Ex sensor.

What maintenance or replacement will the LL3-DV05 fiber-optic cable need over time?

Inspect the polyethylene jacket and polyamide head for abrasion or chemical damage; the PMMA fiber can be re-cut with the supplied cutter if the tip becomes contaminated, but the entire 2 m assembly should be replaced if the fiber core shows micro-cracks or the 90° deflection sleeve is deformed.

What is the first limit that appears when the LL3-DV05 runs continuously at high ambient temperature?

The cable is rated to +70 °C ambient; sustained operation above this temperature degrades the PMMA core and PE jacket faster than mechanical wear, so the thermal limit is reached before the 25 mm bend radius or 0.015 mm minimal object detection are affected.
