M12 cylindrical inductive sensor, chrome-plated brass, 2 m PVC cable

Sick

Sick IM12-06BPS-ZW1 Inductive Proximity Sensor PNP

SKU CH-W8WA-85P1V

A cylindrical M12 inductive proximity sensor with a 6 mm sensing range, PNP normally-open output, and a 2 m PVC cable for 10–30 V DC systems

  • 6 mm sensing range with triple sensing technology
  • PNP normally-open output switches up to 200 mA load
  • IP67 enclosure resists dust and water ingress
  • 10–30 V DC supply with reverse polarity protection
  • M12 × 1 chrome-plated brass housing, 50 mm thread length

M12 inductive proximity sensor for metal detection

The Sick IM12-06BPS-ZW1 is a cylindrical inductive proximity sensor with a 6 mm sensing range and a safe sensing range of 4.86 mm. It operates on 10 V DC to 30 V DC supply voltage and provides a PNP normally open switching output. The sensor suits automation engineers and maintenance technicians who need reliable non-contact metal detection in industrial environments.

Upgrades from shorter-range

This model offers triple sensing range compared to standard M12 sensors, extending detection distance while keeping the same thread size. The 800 Hz switching frequency supports faster cycle times on conveyors or part-presence checks. The jump is worthwhile when existing sensors miss targets at 6 mm or when machine speeds demand higher switching rates.

Quasi-flush mount with 2 m PVC cable

Installation uses the M12 x 1 thread with a maximum tightening torque of 10 Nm and a 50 mm thread length for secure quasi-flush mounting. The 2 m three-wire PVC cable simplifies wiring without separate connectors. Common issues include exceeding the 200 mA continuous current limit, exposure beyond the –25 °C to +70 °C temperature range, or mechanical shock above 30 g.

Highlights

  • 6 mm sensing range with triple sensing technology
  • PNP normally-open output switches up to 200 mA load
  • IP67 enclosure resists dust and water ingress
  • 10–30 V DC supply with reverse polarity protection
  • M12 × 1 chrome-plated brass housing, 50 mm thread length

Specifications

BrandSICK
ModelSICK IM12-06BPS-ZW1

Questions about this item

What thread size and tightening torque does the M12 housing require for mounting?

The sensor uses an M12 x 1 thread with a 50 mm thread length and a maximum tightening torque of 10 Nm.

How do I wire the 3-wire DC PNP cable and what supply voltage is needed?

Connect the 3-wire PVC cable (0.34 mm² conductors) to a 10 V DC to 30 V DC supply; the PNP output switches normally open with a 2 V drop.

When should the cable be inspected or replaced given its PVC jacket and IP67 rating?

Inspect the Ø 5 mm PVC cable regularly for wear, cuts or chemical damage; replace it if the jacket degrades or the IP67 seal is compromised.
