Rectangular zinc die-cast sensor with acrylic window, M12 connector, LC display and two LEDs

Sick

Sick DT50-P1113 Mid Range Distance Sensor

SKU CH-RC72-2N8Q6

Mid-range laser distance sensor measuring 200 mm to 10,000 mm with 1 mm resolution and ±10 mm accuracy

  • Accurate measurements up to 10,000 mm on bright targets
  • Reliable detection down to 6 % remission at 4,000 mm
  • Fast 20 ms response time for dynamic applications
  • Class 2 laser ensures eye-safe operation
  • Rugged IP65 zinc housing withstands harsh environments

Mid-range distance sensor

The SICK DT50-P1113 measures distances from 200 mm to 10,000 mm on natural targets with 90 % remission. It delivers 1 mm resolution and ±10 mm accuracy using a class 2 red laser. The sensor suits automation engineers who need reliable object detection on conveyors or in packaging lines.

Integration requirements

A 10 V to 30 V DC supply with 2.1 W consumption powers the unit through a 5-pin M12 male connector. The zinc die-cast housing with acrylic glass front meets IP65 and protection class III. Builders must provide a compatible cable and mounting; the sensor frees the controller from complex alignment tasks.

Configurable functions

Teach-in, scaling and inversion let the switching and analog outputs adapt to the application. A multifunctional input accepts laser-off, external teach or deactivated signals. The LC display and two LEDs show status, while the moving-average filter can be set to fast or slow response.

Highlights

  • Accurate measurements up to 10,000 mm on bright targets
  • Reliable detection down to 6 % remission at 4,000 mm
  • Fast 20 ms response time for dynamic applications
  • Class 2 laser ensures eye-safe operation
  • Rugged IP65 zinc housing withstands harsh environments

Specifications

BrandSICK
ModelSICK DT50-P1113

Questions about this item

What limits the DT50-P1113 during continuous operation — the 15-minute warm-up or the 100,000-hour laser life?

The sensor needs a 15-minute warm-up before reaching full accuracy, while the laser is rated for 100,000 hours at 25 °C.

How much power does the DT50-P1113 draw and how hot does it get when running all day?

It consumes 2.1 W from a 10–30 V DC supply with 5 Vpp ripple; the IP65 zinc die-cast housing dissipates heat without active cooling.

Which M12 cable and voltage source must I already have to connect the DT50-P1113?

A 5-pin M12 male connector and a 10–30 V DC supply delivering at least 2.1 W are required for operation.
