Silver 3U rack chassis with sixteen front drive bays, three rear fans, seven vertical expansion slots

Shenzhen Junxiangcheng Technology Co.,

Shenzhen Junxiangcheng Technology Co., 3U 16-disk server chassis 12Gb/s Expander backplane Mini-sas HD SFF8643

SKU CH-FTCQ-PXDSB

A 3U server chassis holds sixteen front 3.5-inch drives plus three internal 2.5-inch bays on a 12 Gb/s SAS expander backplane with Mini-SAS HD SFF-8643 links, temperature monitoring and SGPIO.

  • Form Factor3U
  • 16 front hot-swap bays fit 3.5" and 2.5" drives
  • 12Gb/s expander backplane with Mini-sas HD SFF-8643 links
  • 3U depth of 650mm suits dense rack deployments
  • Three hot-swap 12038 fans with temperature control
  • Seven full-height PCIe slots plus dual 2U PSU support

3U 16-bay server chassis

This 3U rackmount chassis fits sixteen front-accessible 3.5-inch drives and three internal 2.5-inch drives. The 12Gb/s Expander backplane uses Mini-sas HD SFF8643 connectors and supports SGPIO and staggered spin-up. It targets cloud storage, big data and security monitoring deployments.

Thermals, noise and power

Three hot-swappable 12038 ball fans provide forced airflow with optional high-pressure variants. The 1.0mm SGCC shell resists fingerprints. A standard 2U or CRPS redundant supply up to 300mm long fits the bay, with 400W to 700W units listed as typical.

Sustained-load behaviour

The expander backplane includes temperature monitoring to regulate fan speed during continuous operation. Seven full-height PCIe slots accept vertical cards for long-running compute or HBA workloads. Front drive trays use anti-EMI guides with LED status columns for ongoing health checks.

Highlights

  • 16 front hot-swap bays fit 3.5" and 2.5" drives
  • 12Gb/s expander backplane with Mini-sas HD SFF-8643 links
  • 3U depth of 650mm suits dense rack deployments
  • Three hot-swap 12038 fans with temperature control
  • Seven full-height PCIe slots plus dual 2U PSU support

Specifications

Form Factor3U

Questions about this item

How do I install the 12Gb/s expander backplane with Mini-sas HD SFF8643 cables in this 3U chassis?

Mount the chassis using its 650mm depth and 437.5mm width rails, connect Mini-sas HD SFF8643 cables from your HBA to the backplane ports, then seat the 16 front 3.5in drive trays until the anti-EMI light guide columns click.

Which parts will need replacement first in the 3U 16-disk server chassis?

The three 12038B ball fans are hot-swappable and rated for continuous operation; plan to swap them when bearing noise rises or airflow drops below spec.

What thermal limit appears first when all 16 drives and three fans run sustained loads?

The backplane temperature control triggers fan-speed ramp or overtemperature alert once the 12Gb/s expander or drive bay zone exceeds its internal threshold.
