White rectangular short-throw LCD projector with front lens and side vents

Sharp

Sharp XP-A824U-W Business Projector 8200 lm WUXGA 20000 h

SKU CH-7AYR-CDY4Y MPN XP-A824U-W

An ultra-short-throw LCD laser projector delivering 8,200 lumens at WUXGA resolution with a 20,000-hour light source and IP5X sealed cooling for maintenance-free operation

  • Cabinet ColorWhite
  • TypeShort Throw LCD
  • Sports TeamNO
  • Brightness8,200 Lumens
  • Native ResolutionWUXGA 1920x1200
  • Maximum Resolution4096 x 2160
  • Sharp's IP5X sealed cooling eliminates lamp replacements and filter cleaning
  • 8,200 lumens brightness keeps audiences engaged in large conference rooms and auditoriums
  • WUXGA 1920x1200 native resolution with 4K 60P playback delivers crystal-clear visuals
  • HDBaseT input and output enables daisy-chaining for effortless multi-projector scalability
  • Preloaded Crestron, Extron, AMX and PJLink support reduces control-system reprogramming

Ultra-Short-Throw LCD Projector

The Sharp XP-A824U-W is a new ultra-short-throw LCD laser projector built for fixed installations in conference rooms, auditoriums and sanctuaries. Its IP5X sealed cooling system removes the need for lamp changes or filter cleaning. With 8,200 lumens and a 3,000,000:1 dynamic contrast ratio, it delivers bright, detailed images on large screens.

Integration-Focused Installers

This model suits AV teams who need native HDBaseT input and output for daisy-chaining multiple units and passing video, audio and control over long cable runs. It fits environments that rely on Crestron, Extron, AMX or PJLink control systems and benefit from competitor command support. Buyers who need a portable projector for occasional use should look elsewhere, as the short-throw lens and installation features are optimised for permanent mounting.

WUXGA Native Resolution

The panel’s native 1920 x 1200 resolution defines the sharpest detail the projector can reproduce without scaling. It accepts signals up to 4096 x 2160 for 4K 60P playback through the onboard video processor, but the displayed image remains WUXGA. If the application demands true 4K pixel density on screen, this native resolution will not meet that requirement.

Highlights

  • Sharp's IP5X sealed cooling eliminates lamp replacements and filter cleaning
  • 8,200 lumens brightness keeps audiences engaged in large conference rooms and auditoriums
  • WUXGA 1920x1200 native resolution with 4K 60P playback delivers crystal-clear visuals
  • HDBaseT input and output enables daisy-chaining for effortless multi-projector scalability
  • Preloaded Crestron, Extron, AMX and PJLink support reduces control-system reprogramming

Specifications

BrandSHARP
SeriesXP-A824U
ModelXP-A824U-W
Part NumberXP-A824U-W
Cabinet ColorWhite
TypeShort Throw LCD
Sports TeamNO
Brightness8,200 Lumens
Native ResolutionWUXGA 1920x1200
Maximum Resolution4096 x 2160
Aspect Ratio16:10
Contrast Ratio3,000,000:1 (with Dynamic Contrast)
Horizontal Refresh Rate15KHz, 24~153KHz
Display Colors1.07 Billion Colors
Throw DistanceMinimum Projection Distance 30"
Maximum Projection Distance 68.50 ft
Projection MethodsFloor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
Lamp Life20000 Hour
Input Video CompatibilityAnalog RGB, Digital
Input Video ConnectorsHDMI, HDBaseT
Output Video ConnectorsHDBaseT
Network ConnectorsRJ45
PanelLCD
Power Supply100-240V AC, 50/60 Hz
Power Consumption635W / 515W / 0.8W / 0.22W
Humidity Range20~85% (non-condensation)
Dimensions23.6 x 8.5 x 19.3 in. / 599 x 216 x 490 mm
Package ContentsA Series XP-A824U-W LCD Projector
Remote Control
Batteries
Power Cord
Quick start guide
Cable cover
Product registration card.
Shipping weight28.71 kg
Package size739 × 625 × 356 mm

Questions about this item

How far back from the screen must the XP-A824U-W sit to project an image?

The projector accepts a throw distance from a minimum of 30 inches up to a maximum of 68.50 feet, so the mounting position can vary widely depending on the lens chosen.

Which connection carries video, audio and control signals in a single cable for daisy-chaining multiple units?

HDBaseT input and output ports pass video, audio and control between projectors, allowing a daisy-chain layout without extra cabling.

When does the sealed cooling system require filter cleaning or light-source replacement?

The IP5X sealed cooling system eliminates filter cleaning, and the laser light source is rated for 20000 hours in normal mode before replacement is needed.
