Sharp
Sharp XP-A155U-W White 1920 x 1200 LCD home theater projector 14000 lumens 3000000:1
Delivers 1920 x 1200 resolution at 14,000 lumens with 3,000,000:1 contrast, supports 4:3, 16:9 and 21:9, and includes dual HDMI 2.0 plus 3G-SDI input
- Cabinet ColorWhite
- TypeLCD
- Aspect RatioSupports 4:3, 16:9, 21:9
- Native Resolution1920 x 1200
- Brightness14,000 lumens
- Contrast Ratio3,000,000:1
- Bright 14000 lumens for clear images in lit rooms
- High 3000000:1 contrast adds depth to dark scenes
- Native 1920 x 1200 resolution shows sharp detail
- Manual keystone up to ±40° horizontal and ±30° vertical
- Two HDMI 2.0 plus 3G-SDI for flexible source connection
Sharp XP-A155U-W 1920 x 1200 LCD projector
The Sharp XP-A155U-W is a new white LCD home-theatre projector delivering a native 1920 x 1200 resolution. It produces 14000 lumens brightness and a 3000000:1 contrast ratio for bright, detailed images. The unit supports 4:3, 16:9 and 21:9 aspect ratios to suit varied content. It is built for fixed installations that demand high light output.
Connectivity and mounting flexibility
Two HDMI 2.0 inputs and one BNC 3G-SDI connector handle professional and consumer video sources. An RJ45 port and a DE-9 RS-232 interface enable network and serial control integration. A 3.5 mm audio output feeds external sound systems. Manual keystone correction covers horizontal ±40° and vertical ±30° for off-axis placement. No built-in speakers are included.
Interchangeable lens system decides fit
The projector ships without a lens and accepts six optional zoom lenses ranging from 12.0 mm to 164.8 mm focal lengths. Throw distance and image size are determined entirely by the chosen lens module. Buyers who need a fixed-lens or ultra-short-throw solution cannot use this model.
Highlights
- Bright 14000 lumens for clear images in lit rooms
- High 3000000:1 contrast adds depth to dark scenes
- Native 1920 x 1200 resolution shows sharp detail
- Manual keystone up to ±40° horizontal and ±30° vertical
- Two HDMI 2.0 plus 3G-SDI for flexible source connection
Specifications
| Brand | SHARP |
|---|---|
| Model | XP-A155U-W |
| Cabinet Color | White |
| Type | LCD |
| Aspect Ratio | Supports 4:3, 16:9, 21:9 |
| Native Resolution | 1920 x 1200 |
| Brightness | 14,000 lumens |
| Contrast Ratio | 3,000,000:1 |
| Keystone Correction | Manual to Horizontal: +/- 40° Manual to Vertical: +/- 30° |
| f Number | (XP-51ZL) F=1.94 to 2.20, f= 12.0 to 14.6mm, (XP-52ZL) F=1.84 to 2.25, f= 14.4 to 19.1mm, (XP-53ZL) F=1.8 to 2.24, f= 19.0 to 27.6mm, (XP-54ZL) F=1.8 to 2.24, f= 27.7 to 44.9mm, (XP-55ZL) F=1.84 to 2.58, f= 43.8 to 87.2mm, (XP-56ZL) F=1.85 to 2.41, f= 86.2 to 164.8mm |
| Input Video Connectors | 2 x HDMI 2.0, 1 x BNC (3G-SDI) |
| Output Audio Connectors | 1x 1/8" / 3.5 mm |
| Network Connectors | RJ45 |
| Other Connectors | 1x DE-9/DB-9 (RS-232) |
| USB | 1 x USB-A |
| Built-in Speakers | No |
| Power Supply | 100 - 240 VAC, 50/60Hz |
| Power Consumption | 960W / 855W / 0.4W / 0.15W |
| Temperature Range | Operating Temperature: 32-113°F / 0-45°C Storage Temperature: 14-122°F / -10-50°C |
| Humidity Range | Operating Humidity: 20 to 85% Humidity (Non-Condensing) Storage Humidity: 20% - 80% (non-condensing) |
| Dimensions | 23.6'' x 9.4'' x 19.3'' |
| Weight | 63.3 lbs. |
Questions about this item
What does the HDMI 2.0 interface cap at for this projector?
The two HDMI 2.0 inputs handle 1920 x 1200 native resolution at up to 60 Hz, so 4K sources are scaled to the panel's WUXGA grid.
What physical mounting dimensions does the XP-A155U-W need?
The chassis is white and designed for ceiling or table mounting with standard VESA-compatible brackets; allow clearance for the 960 W power draw and 0-45 °C operating range.
How is the lens installed, and what step do people get wrong?
Compatible XP-51ZL through XP-56ZL lenses slide into the front bay and lock with a quarter-turn; the common error is skipping the focus-ring calibration after the lens clicks home.
