Schneider Electric XB4BW73731G5 multi-head operator 22 mm 1NO/1NC rectangular

Multi-head Operator 22 mm Rectangle

The Schneider Electric XB4BW73731G5 is a 22 mm rectangular multi-head operator designed for industrial control panels. It combines three distinct operators in a single unit: an extended button, a flush button, and an illuminated indicator light. The chrome-plated metal bezel and metal head construction provide durability in demanding environments. This device suits automation systems requiring compact, multi-function control stations.

Suits Panels Needing Three Functions in One Cutout

This operator fits panels where a single 22 mm opening must accommodate start, stop, and status indication. The green and red colour coding with I/O legends supports clear visual identification. Builders who need only a single pushbutton or a different contact arrangement should look at other products. Installations requiring a different mounting diameter or a non-metal bezel will not match this unit.

10 A 600 V AC Contact Rating with IP69K

The contacts are rated 10 A at 600 V AC under NEMA designations A600 and Q600, suitable for standard industrial control circuits. The assembly carries NEMA 1, 12, 3, 4, 4X and IP66, IP69, IP69K ratings, resisting water ingress during high-pressure washdown. This electrical and environmental rating determines whether the operator meets the safety and durability requirements of a specific application.
