Schneider Electric conduit entry kit, grey plastic rectangular housing with bottom cable openings

Schneider Electric

Schneider Electric VW3A31816 Conduit Entry Kit Type 1 Size 8 ATV312

SKU CH-V17W-JDMTK

A Type 1 conduit entry kit for ATV312 drives, size 8 with 3.76 depth and bottom mounting

  • TypeMotors
  • Conduit entry kit ensures Type 1 compliance for ATV312 drives
  • Bottom-mount design simplifies installation on Size 8 frames
  • Supports single and three-phase power configurations
  • Compatible with multiple Altivar 212 and 312 drive models
  • 76 depth allows compact enclosure integration

Conduit Entry Kit for ATV312 Drives

This Schneider Electric VW3A31816 kit provides a Type 1 conduit entry solution for compatible Altivar drives. It is designed for industrial electrical installations that require a bottom-mounted connection accessory. The kit ensures proper conformity for specific drive models in a single, three-phase configuration.

Type 1 Size 8 Depth 3.76 Mounting

The accessory features a depth of 3.76 and a bottom mounting type for Size 8 drives. It supports the listed ATV312 and ATV212 models including HU55 and HU75 variants across M3, N4, S6, and M3X suffixes. Installations requiring a different mounting orientation or a larger drive frame size will need an alternative kit.

Integration with Altivar Drive Systems

This conformity kit fits directly onto the bottom of the specified drives to complete the conduit connection. It frees the installer from fabricating custom entry plates for these Type 1 applications. The single-unit design simplifies procurement for the supported three-phase drive references.

Highlights

  • Conduit entry kit ensures Type 1 compliance for ATV312 drives
  • Bottom-mount design simplifies installation on Size 8 frames
  • Supports single and three-phase power configurations
  • Compatible with multiple Altivar 212 and 312 drive models
  • 76 depth allows compact enclosure integration

Specifications

BrandSCHNEIDER ELECTRIC
TypeMotors

Questions about this item

Will this VW3A31816 kit fit the ATV312HU55M3 drive I already own?

Yes, the kit is listed for use with the ATV312HU55M3 and ATV312HU75M3 drives, so it will match your existing unit.

How can I confirm the conduit entry kit is correctly installed on my ATV312 drive?

After mounting the kit at the bottom of the drive with a depth of 3.76, verify the conduit entries align and the Type 1 conformity seal is intact.

Does the VW3A31816 package include mounting hardware or must I buy screws separately?

The kit is supplied as a single conformity accessory for ATV312 Size 8 drives; any additional mounting screws are not included and must be sourced separately.
