Transparent enclosed relay with six flat pins square base DIN rail mount

Schneider Electric

Schneider Electric RPF2AB7 Power Relay 24V AC 30A 6 Pin

SKU CH-K9FB-A595F

Enclosed power relay switches 30 A at 250/277 V AC from a 24 V AC coil with six 0.25 in tab terminals

  • TypePower
  • ColorTransparent
  • Handles heavy AC loads with 30 A at 250/277 V
  • Switches DC circuits up to 25 A at 28 V
  • Drives motors rated 3 hp at 240 V AC
  • Mounts on DIN rail or top flange for flexible installs
  • Sealed enclosure protects contacts in harsh environments

Enclosed 24 V AC Power Relay

This Schneider Electric RPF2AB7 is a sealed DPST-NO power relay rated for 30 A at 250/277 V AC and 20 A at 28 V DC. It suits control panels, HVAC equipment and motor circuits that need reliable switching of resistive or inductive loads up to 3 hp at 240 V AC.

Verify Coil Voltage and Mounting Space

Confirm your control circuit supplies 24 V AC to match the coil rating before ordering. The relay uses 1/4 in tab terminals with a 0.25 in flat pin width and mounts on DIN rail or top flange, so check that your enclosure accommodates the 1.38 in body depth and 2.7 in height.

Replaces Open-Frame or Lower-Current Relays

It upgrades from unsealed relays where dust or moisture causes contact failure, or from lower-rated contacts that cannot handle 30 A AC or 25 A DC. The jump is worth it when the application demands a sealed body, DPST-NO switching and the listed horsepower ratings for motor loads.

Highlights

  • Handles heavy AC loads with 30 A at 250/277 V
  • Switches DC circuits up to 25 A at 28 V
  • Drives motors rated 3 hp at 240 V AC
  • Mounts on DIN rail or top flange for flexible installs
  • Sealed enclosure protects contacts in harsh environments

Specifications

BrandSchneider Electric
ModelRPF2AB7
TypePower
ColorTransparent

Questions about this item

What comes with the Schneider Electric RPF2AB7 relay and what must be purchased separately?

The sealed relay with six 0.25 in flat pins is supplied as a single unit. A DIN rail or top-flange mounting hardware and the 24 V AC coil supply are not included.

How do I choose the right version of the RPF2AB7 for my circuit?

The RPF2AB7 is a single model rated 30 A at 250/277 V AC, 20 A at 28 V DC and 25 A at 28 V DC with a 24 V AC coil. Select it only if those voltage and current ratings match your load.

What does the 30 A rating mean when the relay is installed in a real panel?

It means the DPST-NO contacts can continuously switch 30 A at 250/277 V AC or 1 hp at 120 V AC and 3 hp at 240 V AC when mounted on a DIN rail or top flange in a sealed enclosure.
