Transparent replacement coil with IEC terminals

Schneider Electric

Schneider Electric LXD1U7 Replacement Coil 240V AC video accessory

SKU CH-YNT8-C5E88

Replacement coil for CAD relays and LC1D contactors, 240V AC, 70 VA, 50/60 Hz

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Compatible with LC1D09 to D38 contactors for broad IEC system integration
  • Works with LC1DT20 to DT40 contactors covering multiple TeSys Deca models
  • 240V AC coil voltage matches standard industrial control circuits
  • 70 VA coil power rating ensures reliable contactor actuation
  • Operates at 50/60 Hz frequency for global power compatibility

Purpose and fit

The Schneider Electric LXD1U7 is a 240V AC replacement coil designed for IEC-style contactors in the TeSys Deca range. It suits maintenance engineers and panel builders who need to restore coil function on compatible devices without replacing the entire contactor. The transparent housing allows visual inspection of the coil windings. It operates at 50/60 Hz with a 70 VA power rating.

Upgrade scope

This coil replaces a failed or aged coil on LC1D09 through D38 contactors and LC1DT20 through DT40 contactors. The jump is worth it when the contactor mechanism remains sound but the original coil no longer pulls in reliably at 240V AC. It avoids the cost and downtime of swapping the full contactor assembly while keeping the existing wiring and mounting intact.

Who it suits

This part suits technicians servicing IEC contactors in the listed series who have confirmed 240V AC coil voltage and 70 VA rating. It is not for buyers who need a different coil voltage, a higher VA rating, or compatibility with NEMA-sized contactors or other relay series not listed. Installers without access to the contactor model number should verify compatibility before ordering.

Highlights

  • Compatible with LC1D09 to D38 contactors for broad IEC system integration
  • Works with LC1DT20 to DT40 contactors covering multiple TeSys Deca models
  • 240V AC coil voltage matches standard industrial control circuits
  • 70 VA coil power rating ensures reliable contactor actuation
  • Operates at 50/60 Hz frequency for global power compatibility

Specifications

BrandSCHNEIDER ELECTRIC
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Does the LXD1U7 coil fit the LC1D09 through D38 contactors I already have?

Yes, the coil is compatible with Series CAD relays and LC1D09 to D38 contactors, plus LC1DT20 to DT40 contactors and TeSys Deca models.

What is the installation step people often miss when swapping this 240 V AC coil?

Verify the coil voltage matches your 240 V AC supply and confirm the contactor series is CAD or LC1D before removing the old coil and pressing the new one into place.

When will this replacement coil need attention again?

The 70 VA coil runs on 50/60 Hz mains; inspect it during routine panel maintenance and replace it if you hear buzzing, see overheating, or the contactor fails to pull in cleanly.
