Transparent Schneider Electric overload relay with screw terminals

Schneider Electric

Schneider Electric LRD01 Overload Relay 0.1-0.16A 690V AC

SKU CH-4RAH-HB23W

Protects motors from 0.1 to 0.16 A with 690 V AC thermal overload and 1NO/1NC auxiliary contacts

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Protects motors from 0.1 A to 0.16 A overloads with Trip Class 10A response
  • Handles up to 690 V AC for three-phase industrial circuits
  • Dual 1 NO / 1 NC auxiliary contacts signal trip status and control circuits
  • Mounts directly on TeSys Deca contactors using screw-clamp terminals
  • Auto and manual reset options restore operation after a thermal trip

Schneider Electric LRD01 Overload Relay 0.1-0.16A

The Schneider Electric LRD01 is a thermal overload relay designed for motor protection in industrial control panels. It suits maintenance engineers and panel builders who need reliable overload detection for small motors. The unit mounts directly onto compatible TeSys Deca contactors, simplifying assembly and reducing wiring time. It provides a 1NO/1NC auxiliary contact for signalling or control circuit interlocking.

Thermal protection limited to 0.16 A maximum setting

This relay protects motors with a full-load current between 0.10 A and 0.16 A only. The Trip Class 10A characteristic defines a fixed tripping curve that cannot be adjusted for different acceleration times. Maximum operational voltage is 690 V AC, so it cannot be applied to higher voltage networks. Screw clamp terminals accept solid or stranded conductors but do not support spring-cage or ring-terminal connections.

0.10 A to 0.16 A adjustment range decides fit

The single specification that determines suitability is the adjustable current range of 0.10 A to 0.16 A. If the motor nameplate current falls outside this window, the relay will either nuisance-trip or fail to protect. Auto and manual reset modes are both available on the same unit, but the setting range itself is fixed and cannot be extended.

Highlights

  • Protects motors from 0.1 A to 0.16 A overloads with Trip Class 10A response
  • Handles up to 690 V AC for three-phase industrial circuits
  • Dual 1 NO / 1 NC auxiliary contacts signal trip status and control circuits
  • Mounts directly on TeSys Deca contactors using screw-clamp terminals
  • Auto and manual reset options restore operation after a thermal trip

Specifications

BrandSCHNEIDER ELECTRIC
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Which current setting range should I select for my motor circuit?

This relay offers a single adjustable range from 0.10 A minimum to 0.16 A maximum, so choose it when your motor full-load current falls inside that window.

What does the 690V AC rating mean when the relay is installed in a panel?

It is the maximum voltage the relay can safely switch and monitor; the unit is suitable for three-phase systems up to 690 V AC.

How does the screw-clamp terminal connection affect wiring?

Screw-clamp terminals accept stripped solid or stranded conductors and are tightened with a screwdriver for a secure, vibration-resistant joint.
