Transparent IEC magnetic contactor, 4.8 by 2.17 inches, DIN rail mount, screw clamp terminals

Schneider Electric

Schneider Electric LC1D65AL7 200V AC 3P 65A 80A

SKU CH-3MN6-87W20

An IEC magnetic contactor rated 65 A inductive and 80 A resistive at 200 V AC with three poles and DIN-rail mounting

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Handles 65 A inductive loads with 200 V AC coil
  • 80 A resistive rating supports high‑current circuits
  • Three‑pole design switches all phases simultaneously
  • Compact 4.8 in × 2.17 in footprint fits tight panels
  • DIN‑rail or plate mounting speeds up installation

Industrial magnetic contactor for motor control

The Schneider Electric TeSys Deca LC1D65AL7 is a three-pole IEC contactor rated for 65 amps inductive and 80 amps resistive load at 200 volts AC coil voltage. It suits panel builders and maintenance engineers who need reliable switching for motor starters, lighting circuits or heating loads in industrial cabinets.

Verify coil voltage and mounting before ordering

Confirm that your control circuit supplies 200 volts AC to match the coil rating and that the available DIN rail or plate space accommodates the 4.8 inch height and 2.17 inch width. The unit has no enclosure rating, so it must be installed inside a suitable cabinet. Two screw-clamp auxiliary contacts (1NO/1NC) are provided for interlock or status signalling.

Sustained operation at rated current without

The contactor is designed to carry its full 65 amp inductive or 80 amp resistive rating continuously when mounted in free air inside an enclosure. Heat rise remains within IEC limits during prolonged duty cycles, and the screw-clamp terminals maintain low contact resistance over time. Non-reversing operation means a separate contactor pair is required for motor reversal applications.

Highlights

  • Handles 65 A inductive loads with 200 V AC coil
  • 80 A resistive rating supports high‑current circuits
  • Three‑pole design switches all phases simultaneously
  • Compact 4.8 in × 2.17 in footprint fits tight panels
  • DIN‑rail or plate mounting speeds up installation

Specifications

BrandSCHNEIDER ELECTRIC
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Does the LC1D65AL7 contactor ship with any mounting hardware or wiring accessories, or must those be purchased separately?

The contactor is designed for DIN rail or plate mounting and uses screw clamp terminals for wiring; mounting hardware and wire connectors are not included and must be sourced separately.

Should I select the 65 A inductive or the 80 A resistive rating for my motor circuit?

Choose the 65 A inductive rating for motor loads and other inductive applications; the 80 A resistive rating applies only to non-inductive heating or lighting circuits.

What does the 200 V AC coil voltage mean when the contactor is installed in a control panel?

The coil requires a 200 V AC control supply to energise; once powered, the three main poles switch the load circuit while the 1NO/1NC auxiliary contacts provide status feedback.
