Transparent Schneider Electric LC1D12BD contactor with screw terminals, DIN-rail mount, 3.03 in high, 1.77 in wide

Schneider Electric

Schneider Electric LC1D12BD Magnetic Contactor 3-Pole 24V DC 12A

SKU CH-TF3M-6666Q

A 3-pole IEC magnetic contactor switches 12 A inductive or 25 A resistive loads at 24 V DC with screw-clamp terminals on a DIN-rail mount

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Reliable motor switching with 12 A inductive rating
  • Handles resistive loads up to 25 A for versatility
  • Compact 3.03 in height fits tight panels
  • Narrow 1.77 in width saves DIN rail space
  • Secure screw clamp terminals ensure stable wiring

IEC Magnetic Contactor for Industrial Automation

The Schneider Electric LC1D12BD is a three-pole IEC magnetic contactor designed for controlling electrical circuits in industrial automation panels. It operates on a 24V DC coil voltage and handles inductive loads up to 12 A and resistive loads up to 25 A. The unit mounts on a DIN rail or plate and uses screw clamp terminals for secure wiring connections.

Suitable for Motor Starters and Control Panels

This contactor suits electricians and panel builders assembling motor starters, lighting controls or heating circuits where a 24V DC control signal is standard. The 1NO/1NC auxiliary contact block supports status feedback or interlock logic. Buyers needing reversing capability or a higher inductive current rating should look at alternative contactor models.

Verify Coil Voltage and Mounting Space

Confirm that your control circuit supplies 24V DC to match the coil requirement before ordering. Check that the panel provides at least 3.03 in of height and 1.77 in of width for the contactor body. Ensure the DIN rail or mounting plate can accept the TeSys Deca series footprint and that screw clamp terminals suit your wire gauge.

Highlights

  • Reliable motor switching with 12 A inductive rating
  • Handles resistive loads up to 25 A for versatility
  • Compact 3.03 in height fits tight panels
  • Narrow 1.77 in width saves DIN rail space
  • Secure screw clamp terminals ensure stable wiring

Specifications

BrandSchneider Electric
ModelLC1D12BD
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

What coil voltage must the control circuit supply for the LC1D12BD contactor to operate?

The contactor requires a 24 V DC coil voltage; ensure your control circuit provides exactly that level before wiring the coil terminals.

Can the LC1D12BD be mounted on the same DIN rail as older TeSys D contactors?

Yes, it uses the standard DIN rail mounting style, so it fits alongside legacy TeSys D units on the same rail without adapters.

How can I verify the LC1D12BD is switching correctly after installation?

Apply the 24 V DC coil voltage and measure continuity across the three main power poles; each pole should close cleanly, and the built-in 1NO/1NC auxiliary contacts will change state to confirm operation.
