Dark grey rectangular timer module with screw terminals

Schneider Electric

Schneider Electric LADT0 On Delay Timer Module .3-3 sec 690V AC 2.000

SKU CH-61XH-KJ8B7

IEC timer module provides on-delay switching from 0.3 to 3 seconds at up to 690 V AC

  • TypeOn Delay
  • Colordark grey
  • On-delay timing adjustable from 0.3 to 3 seconds
  • 690 V AC rating suits industrial control circuits
  • One normally open and one normally closed contact
  • Screw clamp terminals give secure wiring connections
  • Compatible with TeSys Deca starter series

IEC Timer Module for TeSys Deca Starters

This Schneider Electric LADT0 module provides an on-delay function with a single normally open and one normally closed contact. It mounts on the front of compatible TeSys Deca starters using screw clamp terminals. The unit operates up to a maximum voltage of 690V AC and withstands ambient temperatures up to 158 degrees Fahrenheit. It suits control panels requiring a fixed short delay before circuit energisation.

Replaces Fixed-Time Relays

The jump is worth it when the application demands a precise delay window between 0.3 and 3 seconds. Builders needing delays shorter than 0.3 seconds or longer than 3 seconds must select a different module. The 2.000 designation confirms the specific timing characteristic for this unit. It is not for systems requiring instantaneous switching or multi-range programmability.

Limited to Screw Clamp Wiring

The screw clamp terminals accept solid or stranded conductors but exclude spring-cage or ring-lug connections. Front mounting restricts installation to accessible starter faces; DIN-rail or base mounting is not supported. The 690V AC rating defines the insulation limit for the control circuit. No other interface or communication protocol is provided.

Highlights

  • On-delay timing adjustable from 0.3 to 3 seconds
  • 690 V AC rating suits industrial control circuits
  • One normally open and one normally closed contact
  • Screw clamp terminals give secure wiring connections
  • Compatible with TeSys Deca starter series

Specifications

BrandSchneider Electric
ModelLADT0
TypeOn Delay
Colordark grey

Questions about this item

Will the screw-clamp terminals accept the wire gauge used with a TeSys Deca starter?

The module mounts on the front of a TeSys Deca starter and uses screw-clamp terminals for wiring; wire gauge is set by the starter’s own terminal specification.

How do I set the 0.3 to 3 second delay without overshooting the minimum?

Turn the adjustment dial slowly from the lowest mark toward 3 seconds; the dial is calibrated so the first detent corresponds to the 0.3 second minimum.

Does the 158 °F temperature rating mean I need extra ventilation inside the enclosure?

The unit is rated for a maximum operating temperature of 158 °F; if the enclosure interior stays below that level no additional ventilation is required for the timer itself.
