Schneider Electric 9001SKS11BH2 selector switch 30 mm 2 position lever
30 mm two-position maintained lever selector switch with DPDT contacts rated 10 A at 600 V AC and NEMA 12, 13, 3, 3R, 4, 4X plus IP66 protection
- 30 mm mounting fits standard panels
- Two maintained lever positions for clear on/off control
- DPDT contacts rated 10 A at 600 V AC
- NEMA 12, 13, 3, 3R, 4, 4X and IP66 protection
- Polycarbonate operator head with chrome bezel for durability
30 mm selector switch for industrial panels
The Schneider Electric 9001SKS11BH2 is a 30 mm non-illuminated selector switch built for machinery and machine-shop control panels. It uses a black lever operator with a chrome plastic bezel and a polycarbonate head on a plastic base. The switch is rated for new condition and carries NEMA 12, 13, 3, 3R, 4, 4X and IP66 environmental ratings.
DPDT contacts and cam E switching sequence
The unit provides a DPDT contact form rated 10A at 600V AC with NEMA designations A600 and Q600. Its maintained two-position action follows cam E logic: position A gives OXOX contact states while position B gives XOXO, with no third position defined. The lever operator requires no key removal and is designed for direct panel mounting.
Suits panels needing maintained two-position control
This switch fits applications that need a rugged, maintained two-position selector with high environmental sealing. It is not suited for momentary-action requirements, illuminated operator needs, key-operated security, or configurations demanding a third switch position. Buyers requiring different contact forms or voltage ratings should verify compatibility before ordering.
Highlights
- 30 mm mounting fits standard panels
- Two maintained lever positions for clear on/off control
- DPDT contacts rated 10 A at 600 V AC
- NEMA 12, 13, 3, 3R, 4, 4X and IP66 protection
- Polycarbonate operator head with chrome bezel for durability
Specifications
| Brand | SCHNEIDER ELECTRIC |
|---|
Questions about this item
How often will the DPDT contacts rated at 10A @ 600V AC need replacement under normal use?
The DPDT contacts are rated for 10A at 600V AC with NEMA A600/Q600 designation, designed for long service life in industrial control circuits; replacement timing depends on actual switching frequency and load conditions.
What operational limit appears first during continuous duty with the maintained lever positions?
The selector switch carries NEMA 12, 13, 3, 3R, 4, 4X and IP66 ratings, so the practical limit under sustained use is the 10A contact rating rather than environmental sealing.
Does the polycarbonate operator head generate noticeable heat or noise when the switch runs all day?
As a passive mechanical selector with no internal electronics, the switch produces no operational noise or measurable heat during continuous all-day operation.
