Schneider Electric 9001KS53BH1 selector switch 30 mm 3 position black
A 30 mm three-position selector switch with momentary and maintained actions, SPDT contacts rated 10 A at 600 V AC, NEMA 12/13/3/3R/4 and IP65 protection, black polycarbonate lever on a metal bezel
- 3-position selector switch for flexible control
- 30 mm mounting fits standard panels
- IP65 rated for dust and water protection
- 10 A at 600 V AC contact rating
- NEMA 12, 13, 3, 3R, 4 enclosure rating
30 mm Three-Position Selector Switch
This Schneider Electric 9001KS53BH1 selector switch mounts in a 30 mm cutout and provides three operating positions with a black polycarbonate lever on a metal bezel. It is built for industrial control panels that need a compact, manually operated switching device with a clear tactile feel.
IP65 and NEMA 12 13 3 3R 4 Enclosure Ratings
The operator head carries an IP65 rating and meets NEMA 12, 13, 3, 3R and 4 requirements, so dust, splashing water and oil do not reach the internal contacts. Contacts are rated 10A at 600V AC under the A600/Q600 designation, allowing direct pilot-duty switching without auxiliary relays.
Cam C Momentary Maintained Momentary Action
Cam C gives a momentary action at positions A and C with a maintained centre position B, and the contact state follows the OX, OO, XO sequence across the three positions. The switch ships with no key removal feature and the black metal bezel matches standard panel aesthetics, so installers can mount it directly without extra hardware.
Highlights
- 3-position selector switch for flexible control
- 30 mm mounting fits standard panels
- IP65 rated for dust and water protection
- 10 A at 600 V AC contact rating
- NEMA 12, 13, 3, 3R, 4 enclosure rating
Specifications
| Brand | SCHNEIDER ELECTRIC |
|---|
Questions about this item
How is the 30 mm selector switch mounted and which step is often missed?
Drill a 30 mm panel cut-out, insert the operator through the front, and secure the metal bezel with the locking nut from behind; the step most installers forget is tightening the nut to the specified torque so the IP65 seal seats evenly.
What maintenance will the selector switch need over its service life?
Periodically inspect the polycarbonate lever and metal bezel for cracks or corrosion, verify the SPDT contacts remain clean and tight, and replace the complete operator head if the lever action becomes stiff or the NEMA 12/13/3/3R/4 rating is compromised.
What is the first limit reached during continuous operation at full load?
The 10 A / 600 V AC contact rating (NEMA A600/Q600) is the limiting factor; sustained current above 10 A will overheat the SPDT contacts before the IP65 enclosure or cam mechanism shows wear.
