Small cylindrical lamp module with clear plastic lens and screw terminals

Schneider Electric

Schneider Electric 9001KM35 Lamp Module 30mm 24-28VAC/VDC Clear Incandescent

SKU CH-QYRK-DZMF9

A 30 mm clear incandescent lamp module rated for 24 to 28 V AC/DC with screw-clamp terminals and NEMA 1, 2, 3, 4, 4X, 12, 13 plus IP20 protection

  • Engine BrandSCHNEIDER ELECTRIC
  • Engine Size30 mm
  • Clear incandescent lamp for visible status indication
  • Full-voltage 24-28 V AC/DC operation suits industrial control circuits
  • Screw-clamp terminals enable secure wiring without special tools
  • NEMA 1, 2, 3, 4, 4X, 12, 13 and IP20 ratings protect against dust and water ingress
  • Direct replacement for Schneider 9001 illuminated operators with lamp number 25501-010-02

30 mm Incandescent Lamp Module

The Schneider Electric 9001KM35 is a 30 mm clear incandescent lamp module rated for 24-28 VAC/VDC operation. It uses a screw-clamp terminal connection and carries NEMA ratings 1, 2, 3, 4, 4X, 12 and 13 alongside an IP20 rating. The module is built from plastic and meets EN/IEC 60947-1, 60947-5-1, 60947-5-4, JIS C 4520, JIS C 852, UL 508 and CSA C22.2 No 14 standards. It serves as a direct replacement lamp for 9001 illuminated operators and pilot lights.

Replaces 25501-010-02 Lamp

This module replaces the manufacturer part 25501-010-02 when the existing lamp fails or dims beyond useful output. The jump is worth it when the original incandescent bulb reaches end of life and a like-for-like voltage and base match is required. It is not suited for installations that demand LED efficiency, lower heat output or a different voltage range than 24-28 VAC/VDC.

Fits 9001 Illuminated Operators

The module mounts into 9001 series illuminated operators and pilot lights using the integrated screw-clamp terminals. Its plastic construction and NEMA 4X rating allow use in wash-down and corrosive environments where the enclosure provides the seal. It frees the installer from sourcing separate bulbs and holders by combining both in a single 30 mm unit.

Highlights

  • Clear incandescent lamp for visible status indication
  • Full-voltage 24-28 V AC/DC operation suits industrial control circuits
  • Screw-clamp terminals enable secure wiring without special tools
  • NEMA 1, 2, 3, 4, 4X, 12, 13 and IP20 ratings protect against dust and water ingress
  • Direct replacement for Schneider 9001 illuminated operators with lamp number 25501-010-02

Specifications

Engine BrandSCHNEIDER ELECTRIC
Engine Size30 mm

Questions about this item

What panel cut-out size does the 30 mm lamp module require?

The module is built for a standard 30 mm mounting hole used by the 9001 illuminated operator range.

How is the module wired and which step is often missed?

Connect the supply wires to the screw-clamp terminals; the step often missed is tightening both screws to secure each conductor.

Which replacement lamp fits this module when the incandescent bulb fails?

Use the replacement lamp with manufacturer number 25501-010-02.
