sakose BT-M260U3F 2.5" dual-bay USB 3.0 FireWire RAID enclosure
A dual-bay 2.5-inch SATA enclosure with USB 3.0 and FireWire, hardware RAID 0/1 and JBOD, tool-less trayless bays, and a 750 GB per-bay limit
- ColorBlack
- Size2.5"
- AC AdapterYes
- Internal InterfaceSATA I/II
- External InterfaceUSB 3.0
- Maximum Capacity (per Bay)Up to 750GB (9.5mm Height)
- Tool-less tray-less design lets you swap 2.5" drives in seconds
- Hardware RAID 0, RAID 1 and JBOD modes protect or accelerate data
- USB 3.0 SuperSpeed up to 5 Gbps with USB 2.0 backward compatibility
- Dual FireWire ports extend connectivity to legacy Mac and PC workflows
- Built-in fan and 9.5 mm bay height keep two 750 GB drives cool
Dual-bay 2.5" USB 3.0 RAID enclosure
The sakose BT-M260U3F houses two 2.5-inch SATA hard drives or SSDs in a single black chassis. It connects to a host via SuperSpeed USB 3.0 and also provides FireWire ports. An included AC adapter powers the unit and an internal fan assists cooling.
Suits users wanting hardware RAID
The enclosure supports hardware RAID 0 striping, RAID 1 mirroring, JBOD spanning and a non-RAID mode presenting two independent SATA volumes. Tool-less, tray-less bays allow quick drive swaps. It is not suited for 3.5-inch drives or for single-drive portable use.
Maximum 750 GB per bay at 9.5 mm height
Each bay accepts drives up to 750 GB capacity and 9.5 mm thickness. Thicker or higher-capacity drives cannot be installed. The SATA I/II internal interface sets the drive speed ceiling.
Highlights
- Tool-less tray-less design lets you swap 2.5" drives in seconds
- Hardware RAID 0, RAID 1 and JBOD modes protect or accelerate data
- USB 3.0 SuperSpeed up to 5 Gbps with USB 2.0 backward compatibility
- Dual FireWire ports extend connectivity to legacy Mac and PC workflows
- Built-in fan and 9.5 mm bay height keep two 750 GB drives cool
Specifications
| Brand | SAKOSE |
|---|---|
| Model | BT-M260U3F |
| Color | Black |
| Size | 2.5" |
| AC Adapter | Yes |
| Internal Interface | SATA I/II |
| External Interface | USB 3.0 |
| Maximum Capacity (per Bay) | Up to 750GB (9.5mm Height) |
| Fan | Yes |
| Specifications | Storage Policy: Hardware Raid 0 (Striping) Hardware Raid 1 (Mirroring) JBOD (spanning) Non-Raid (USB 3.0 to 2x Sata) |
| Operating Systems Supported | Windows 98/2000/ME/XP/Vista/7 and Max OS 9.x/10.x and above, Linux kernel after 2.4.1.0 |
| Features | Easy open and lock door Tool-less design for HDD installation, Trayless design - Fast HDD exchanging Compliant with USB 3.0 Spec Revision 1.0 Supports the following speed data rate: Low-speed(1.5Mbps)/ Full-speed(12Mbps)/ High-speed(480Mbps)/ Super-speed(5Gbps) Auto negotiation between SATA I (1.5Gbps) & SATA II (3.0 Gbps) Firewire ports are compliant with IEEE 1394a-2000 and IEEE 1394-1995 Supports the following 1394 speeds: S100/S200/S400/S400B/S800B Support DIP Switch to Configure the Storage Policy Supports LEDs for Power & HDD activities indication Smart Cooling Fan No Software |
Questions about this item
What does the 5 Gbps USB 3.0 speed mean for real-world transfers with two drives installed?
The 5 Gbps link is shared between both bays; each drive can reach SATA I/II rates, but simultaneous heavy traffic on both drives will divide the available bandwidth.
How do the USB 3.0 and FireWire ports limit the RAID modes I can use?
Hardware RAID 0, RAID 1 and JBOD operate over either USB 3.0 or FireWire; Non-RAID mode presents both drives independently only through the USB 3.0 connection.
Which 2.5-inch drives physically fit in the bays?
Any 2.5-inch SATA HDD or SSD up to 9.5 mm thick and 750 GB per bay will slide into the tool-less trayless slots.
