Sabrent
Sabrent EC-DFLT USB 3.0 SATA Lay-Flat Docking Station 2.5 3.5in 10 Bay
A ten-bay lay-flat dock that lets you hot-swap 2.5" and 3.5" SATA drives over USB 3.0 at up to 5 Gbps
- ColorBlack
- Size2.5" & 3.5"
- TypeDock
- Internal InterfaceSATA I/II/III
- External InterfaceUSB 3.0
- Number of Bay10
- 10 drive bays for simultaneous access to multiple SATA disks
- USB 3.0 interface delivers up to 5 Gbps transfer speed
- Hot-swappable design lets you swap drives without rebooting
- Accepts both 2.5" and 3.5" SATA hard drives or SSDs
- Plug-and-play operation requires no driver installation
Direct-insert SATA dock
The Sabrent EC-DFLT is a lay-flat docking station that accepts 2.5 and 3.5 inch SATA hard drives or SSDs. It provides ten bays for high-volume drive swapping without enclosures. The dock connects through USB 3.0 and works with Windows from 2000 through 10 plus Mac OS X. No drivers are required for operation.
Passive cooling and USB power
The unit has no fan, so it runs silently while drives are seated in the open bays. A 12 V AC adapter supplies power to the dock and the installed drives. Data moves at up to 5 Gbps over USB 3.0 and falls back to 480 Mbps on USB 2.0 or 1.1 ports. An on-off switch cuts power to all bays at once.
Build integration and drive flexibility
The dock needs a free USB 3.0 port and a mains outlet for its power supply. It frees the builder from fitting multiple internal drive cages or hot-swap bays inside the chassis. Each bay takes any capacity SATA drive up to 8 TB, and drives can be inserted or removed while the system is running.
Highlights
- 10 drive bays for simultaneous access to multiple SATA disks
- USB 3.0 interface delivers up to 5 Gbps transfer speed
- Hot-swappable design lets you swap drives without rebooting
- Accepts both 2.5" and 3.5" SATA hard drives or SSDs
- Plug-and-play operation requires no driver installation
Specifications
| Brand | SABRENT |
|---|---|
| Model | EC-DFLT |
| Color | Black |
| Size | 2.5" & 3.5" |
| Type | Dock |
| Internal Interface | SATA I/II/III |
| External Interface | USB 3.0 |
| Number of Bay | 10 |
| Fan | No |
| Operating Systems Supported | Windows XP, Windows Vista, Windows 7, Windows 8 Mac OS |
| Features | Easy to dock/undock of SATA hard drives. Super fast USB 3.0 data transfer speeds up to 5Gbps. Supports 2.5”/3.5” SATA Hard Drives. Plug & Play, no software needed. Supports hard drives up to any capacity. Includes 12V/2.5A AC power adapter, so dock will work connected to any USB port. |
| Package Contents | 2.5" /3.5" external SATA hard disk docking AC Power Adapter USB 3.0 Cable |
| Shipping weight | 0.59 kg |
| Package size | 269 × 142 × 74 mm |
Questions about this item
How do I install a drive in the Sabrent EC-DFLT 10-bay dock and what step do people miss?
Connect the 12 V power adapter, link the USB 3.0 cable to the host, press the On/Off switch, then insert a 2.5" or 3.5" SATA drive straight down until it seats; the step most people miss is powering the dock on before inserting the drive.
What maintenance or replacement will the Sabrent EC-DFLT dock need later?
The unit has no fan and no user-serviceable parts; only the external 12 V power adapter or the USB 3.0 cable may need replacement if they fail.
What limit appears first on the Sabrent EC-DFLT during sustained transfers?
The USB 3.0 interface caps sustained throughput at 5 Gbps, so that bus limit is reached before any single SATA drive can saturate the connection.
