Compact desktop switch with eight RJ-45 ports and two SFP uplinks

RUCKUS WIRELESS

RUCKUS WIRELESS ICX8100-C08PF 8-port PoE+ network switch

SKU CH-KFED-4DCZP MPN ICX8100-C08PF

Managed 8-port Gigabit PoE+ switch delivering up to 30W per port with 124W total budget and two SFP uplinks

  • FormatDesktop
  • Standards802.1AB LLDP/ LLDP-MED 802.1D MAC Bridging 802.1p Mapping to
  • Network Management TypeManaged
  • Management FeatureDHCP Auto-Configuration Configuration Logging Digital Optica
  • MAC Address Table32K
  • Jumbo FramesMaximum jumbo frame size: 9,216 bytes
  • 8 PoE+ ports deliver up to 30 W each for powering access points and cameras
  • 124 W total PoE budget supports multiple high-draw devices simultaneously
  • Two 1 GbE SFP uplinks provide flexible fibre or copper backbone connections
  • Managed Layer 2 feature set includes 802.1X, MSTP and DHCP snooping for secure segmentation
  • 42 Mpps forwarding rate with 9 216-byte jumbo frames handles latency-sensitive traffic

Compact 8-port PoE+ switch

The RUCKUS ICX 8100-C08PF is a managed desktop switch with eight 10/100/1000 Mbps RJ-45 ports that deliver PoE+ power up to 30 W each. A total PoE budget of 124 W supports wireless access points, IP cameras or VoIP phones in small branches or retail sites. Two 1 GbE SFP uplink ports provide fibre or copper uplinks to the core network. Layer 3 static routing and a full set of 802.1 security and QoS features are included.

Suited for PoE edge deployments without a rack

This switch fits installations that need a compact, fanless form factor and a single PoE budget for up to eight devices. It is not for environments that require modular uplink slots, redundant power supplies or higher port densities beyond eight copper ports. Buyers who need Layer 3 dynamic routing protocols or stacking across multiple units should evaluate other platforms. The 4 MB packet buffer and 42 Mpps forwarding rate are sized for typical access-layer traffic.

124 W total PoE budget decides port loading

The 124 W budget is the single figure that determines how many Class 4 devices can be powered simultaneously. At the maximum 30 W per port, only four ports can draw full power at once; the remaining ports must share the residual budget. Planning the actual device mix against this limit confirms whether the switch meets the deployment requirement.

Highlights

  • 8 PoE+ ports deliver up to 30 W each for powering access points and cameras
  • 124 W total PoE budget supports multiple high-draw devices simultaneously
  • Two 1 GbE SFP uplinks provide flexible fibre or copper backbone connections
  • Managed Layer 2 feature set includes 802.1X, MSTP and DHCP snooping for secure segmentation
  • 42 Mpps forwarding rate with 9 216-byte jumbo frames handles latency-sensitive traffic

Specifications

BrandFortinet
SeriesRUCKUS ICX 8100
ModelICX 8100-C08PF PoE
Part NumberICX8100-C08PF
FormatDesktop
Standards802.1AB LLDP/ LLDP-MED
802.1D MAC Bridging
802.1p Mapping to Priority Queue
802.1s Multiple Spanning Tree (MST)
802.1w Rapid Reconfiguration of Spanning Tree (RSTP)
802.1x Port-based Network Access Control (PNAC)
802.3 Carrier Sense Multiple Access/Collision Detection (CSMA/CD)
802.3ab 1000BASE-T
802.3 10Base-T
802.3ad Link Aggregation (Dynamic and Static)
802.1 AX-2008 Link Aggregation
802.3ae 10 Gigabit Ethernet
802.3af Power over Ethernet
802.3at Power over Ethernet Plus
802.3bz Multigigabit Ethernet
802.3u 100Base-TX
802.3x Flow Control
802.3z 1000Base-SX/LX
802.3 MAU MIB (RFC 22
Network Management TypeManaged
Management FeatureDHCP Auto-Configuration
Configuration Logging
Digital Optical Monitoring
Display Log Messages on Multiple Terminals
Embedded Web Management (HTTP/HTTPS)
Embedded DHCP Server
Industry-standard Command Line Interface (CLI)
RUCKUS SmartZone, RUCKUS One, RUCKUS Unleashed
CLI activation of optional software features
Macro for batch execution
RSPAN
TFTP
TELNET Client and Server
SSH / SSH V2
Bootp
SNMPv1/v2c
DHCP Server and DHCP Relay
SNMPv3 Intro to Framework
Architecture for Describing SNMP Framework
SNMP Message Processing and Dispatching
SNMPv3 Applications
SNMPv3 User-based Security Mo
MAC Address Table32K
Jumbo FramesMaximum jumbo frame size: 9,216 bytes
Packet Forwarding RateForwarding capacity (data rate, full duplex): 42 Mpps
Buffer Memory4 MB
Security802.1X authentication
MAC authentication
Flexible authentication
Web authentication
DHCP snooping
Dynamic ARP inspection
Neighbor Discovery (ND) Inspection
Bi-level Access Mode (Standard and EXEC Level)
EAP pass-through support
IEEE 802.1X username export in sFlow
Protection against Denial of Service (DoS) attacks
Authentication, Authorization, and Accounting (AAA)
MAC Address Locking MAC Port Security
Advanced Encryption Standard (AES) with SSHv2
RADIUS/TACACS/TACACS+
Secure Copy (SCP)
Secure Shell (SSHv2)
Protected Ports
Local Username/Password
Change of Authorization (CoA) RFC 517
PoEYes
QoSQoS priority queues: 8 per port
Quality of Service (QoS):
ACL Mapping and Marking of ToS/DSCP (CoS)
ACL Mapping and Marking of 802.1p
ACL Mapping to Priority Queue
Classifying and Limiting Flows Based on TCP Flags
DiffServ Support
Honoring DSCP and 802.1p (CoS)
MAC Address Mapping to Priority Queue
Priority Queue Management using Weighted Round Robin (WRR), Strict Priority (SP), and a combination of WRR and SP
Layer802.1s Multiple Spanning Tree
802.1x Authentication
Auto MDI/MDIX
BPDU Guard, Root Guard
Dual-Mode VLANs
MAC-based VLANs, Dynamic MAC-based VLAN activation
Dynamic VLAN Assignment
Dynamic Voice VLAN Assignment
Fast Port Span
GVRP : GARP VLAN Registration Protocol
IGMP Snooping (v1/v2/v3)
IGMP Proxy for Static Groups
IGMP v2/v3 Fast Leave
Inter-Packet Gap (IPG) adjustment
Link Fault Signaling (LFS)
MAC Address Filtering
MAC Learning Disable
MLD Snooping (v1/v2)
Multi-device Authentication
Per-VLAN Spanning Tree (PVST/PVST+/PRST)
Mirroring: Port-based, ACL-based, MAC Filter-based, and
Layer 3 FeaturesBase Layer 3 IP routing:
Routing not supported
Static Routing
Shipping weight2.27 kg
Package size272 × 216 × 46 mm

Questions about this item

How do I install the ICX8100-C08PF and what step is often missed?

Place the desktop switch on a stable surface, connect devices to the 8 RJ-45 PoE+ ports and uplinks to the 2 SFP ports, then apply power — the power cord is not included and must be sourced separately.

What maintenance or replacement will the ICX8100-C08PF need later?

The switch has no user-replaceable fans or power supply; plan for eventual unit replacement if internal components fail, and keep firmware updated via the embedded web management or CLI.

What limit appears first on the ICX8100-C08PF under sustained heavy load?

The 124 W total PoE budget caps simultaneous 30 W Class 4 ports at four; the 4 MB buffer and 42 Mpps forwarding rate handle bursts, but PoE power runs out before throughput saturates.
