Silver 1U rackmount switch with 24 RJ45 ports and four SFP+ uplinks

RUCKUS WIRELESS

RUCKUS WIRELESS ICX8100-24P-X 24-port PoE+ network switch

SKU CH-RY52-7TM89 MPN ICX8100-24P-X

Managed 24-port Gigabit PoE+ switch with four 10 GbE SFP+ uplinks and a 370 W power budget

  • Switch TypeICX8100-24P-X
  • Standards802.1AB LLDP/ LLDP-MED 802.1D MAC Bridging 802.1p Mapping to
  • Network Management TypeManaged
  • Management FeatureDHCP Auto-Configuration Configuration Logging Digital Optica
  • MAC Address Table32K
  • Jumbo FramesMaximum jumbo frame size: 9,216 bytes
  • 24 PoE+ ports power access points and cameras directly
  • 370 W PoE budget supports 30 W per port for high-demand devices
  • Four 10 GbE SFP+ uplinks provide high-speed backbone connectivity
  • 42 Mpps forwarding capacity handles heavy traffic without bottlenecks
  • 32 K MAC address table scales for growing network environments

RUCKUS ICX 8100 24-port PoE+ switch

The RUCKUS ICX 8100-24P-X is a managed 1RU switch with 24 RJ-45 ports running at 10/100/1000 Mbps and four 10GbE SFP+ uplinks. It delivers PoE+ 802.3at power up to 30W per port across all 24 ports. The unit suits network teams needing wired and wireless convergence with AI-driven management options.

370W PoE budget and uplink flexibility

A 370W PoE budget feeds access points, cameras or phones without external injectors. Four 10GbE SFP+ uplinks connect to aggregation or core layers at 10 Gbps. The switch requires SFP+ modules and fibre or copper cabling for uplinks, plus a power cord sourced separately. It frees rack space by combining PoE and 10G uplinks in one 1RU chassis.

Sustained forwarding at 42 Mpps

The forwarding capacity reaches 42 Mpps full duplex with a 9,216-byte jumbo frame limit and 4 MB buffer. Eight QoS priority queues per port and ACL-based marking maintain consistent latency for voice and video under continuous load. Base Layer 3 static routing handles inter-VLAN traffic without dynamic protocols. The 32K MAC table supports dense endpoint environments.

Highlights

  • 24 PoE+ ports power access points and cameras directly
  • 370 W PoE budget supports 30 W per port for high-demand devices
  • Four 10 GbE SFP+ uplinks provide high-speed backbone connectivity
  • 42 Mpps forwarding capacity handles heavy traffic without bottlenecks
  • 32 K MAC address table scales for growing network environments

Specifications

BrandFortinet
SeriesRUCKUS ICX 8100
ModelICX 8100-24P PoE w/ 4x 1/10GbE SFP+ uplink ports
Part NumberICX8100-24P-X
Switch TypeICX8100-24P-X
Standards802.1AB LLDP/ LLDP-MED
802.1D MAC Bridging
802.1p Mapping to Priority Queue
802.1s Multiple Spanning Tree (MST)
802.1w Rapid Reconfiguration of Spanning Tree (RSTP)
802.1x Port-based Network Access Control (PNAC)
802.3 Carrier Sense Multiple Access/Collision Detection (CSMA/CD)
802.3ab 1000BASE-T
802.3 10Base-T
802.3ad Link Aggregation (Dynamic and Static)
802.1 AX-2008 Link Aggregation
802.3ae 10 Gigabit Ethernet
802.3af Power over Ethernet
802.3at Power over Ethernet Plus
802.3bz Multigigabit Ethernet
802.3u 100Base-TX
802.3x Flow Control
802.3z 1000Base-SX/LX
802.3 MAU MIB (RFC 22
Network Management TypeManaged
Management FeatureDHCP Auto-Configuration
Configuration Logging
Digital Optical Monitoring
Display Log Messages on Multiple Terminals
Embedded Web Management (HTTP/HTTPS)
Embedded DHCP Server
Industry-standard Command Line Interface (CLI)
RUCKUS SmartZone, RUCKUS One, RUCKUS Unleashed
CLI activation of optional software features
Macro for batch execution
RSPAN
TFTP
TELNET Client and Server
SSH / SSH V2
Bootp
SNMPv1/v2c
DHCP Server and DHCP Relay
SNMPv3 Intro to Framework
Architecture for Describing SNMP Framework
SNMP Message Processing and Dispatching
SNMPv3 Applications
SNMPv3 User-based Security Mo
MAC Address Table32K
Jumbo FramesMaximum jumbo frame size: 9,216 bytes
Packet Forwarding RateForwarding capacity (data rate, full duplex): 42 Mpps
Buffer Memory4 MB
Security802.1X authentication
MAC authentication
Flexible authentication
Web authentication
DHCP snooping
Dynamic ARP inspection
Neighbor Discovery (ND) Inspection
Bi-level Access Mode (Standard and EXEC Level)
EAP pass-through support
IEEE 802.1X username export in sFlow
Protection against Denial of Service (DoS) attacks
Authentication, Authorization, and Accounting (AAA)
MAC Address Locking MAC Port Security
Advanced Encryption Standard (AES) with SSHv2
RADIUS/TACACS/TACACS+
Secure Copy (SCP)
Secure Shell (SSHv2)
Protected Ports
Local Username/Password
Change of Authorization (CoA) RFC 517
PoEYes
QoSQoS priority queues: 8 per port
Quality of Service (QoS):
ACL Mapping and Marking of ToS/DSCP (CoS)
ACL Mapping and Marking of 802.1p
ACL Mapping to Priority Queue
Classifying and Limiting Flows Based on TCP Flags
DiffServ Support
Honoring DSCP and 802.1p (CoS)
MAC Address Mapping to Priority Queue
Priority Queue Management using Weighted Round Robin (WRR), Strict Priority (SP), and a combination of WRR and SP
Layer802.1s Multiple Spanning Tree
802.1x Authentication
Auto MDI/MDIX
BPDU Guard, Root Guard
Dual-Mode VLANs
MAC-based VLANs, Dynamic MAC-based VLAN activation
Dynamic VLAN Assignment
Dynamic Voice VLAN Assignment
Fast Port Span
GVRP : GARP VLAN Registration Protocol
IGMP Snooping (v1/v2/v3)
IGMP Proxy for Static Groups
IGMP v2/v3 Fast Leave
Inter-Packet Gap (IPG) adjustment
Link Fault Signaling (LFS)
MAC Address Filtering
MAC Learning Disable
MLD Snooping (v1/v2)
Multi-device Authentication
Per-VLAN Spanning Tree (PVST/PVST+/PRST)
Mirroring: Port-based, ACL-based, MAC Filter-based, and
Layer 3 FeaturesBase Layer 3 IP routing:
Routing not supported
Static Routing
Shipping weight4.54 kg
Package size442 × 282 × 46 mm

Questions about this item

How many PoE+ ports does the ICX8100-24P-X provide before I need additional power budget?

The switch has 24 PoE+ ports, each delivering up to 30W, with a total PoE budget of 370W across all ports.

What is the fan noise and heat output when the ICX8100-24P-X runs continuously at full PoE load?

The 1RU chassis uses internal fans that scale speed with temperature; sustained 370W PoE load increases airflow and audible fan noise in a typical rack.

Which SFP+ transceivers and cables must I already own to use the four uplink ports?

The four 1/10GbE SFP+ uplink ports accept standard SFP+ modules and direct-attach cables for 1GbE or 10GbE links.
