Silver 1U rackmount network switch with 24 RJ-45 ports and 4 SFP uplinks

RUCKUS WIRELESS

RUCKUS WIRELESS ICX8100-24P 24-port PoE+ network switch

SKU CH-CGRJ-8EGMP MPN ICX8100-24P

Managed 24-port Gigabit PoE+ switch with 370W budget and four SFP uplinks

  • Switch TypeICX8100-24P
  • Standards802.1AB LLDP/ LLDP-MED 802.1D MAC Bridging 802.1p Mapping to
  • Network Management TypeManaged
  • Management FeatureDHCP Auto-Configuration Configuration Logging Digital Optica
  • MAC Address Table32K
  • Jumbo FramesMaximum jumbo frame size: 9,216 bytes
  • 24 PoE+ ports deliver up to 30 W each for power-hungry devices
  • 370 W total PoE budget supports dense endpoint deployments
  • 4 SFP uplink ports provide 1 GbE fibre connectivity
  • 42 Mpps forwarding capacity handles heavy traffic loads
  • Managed switch with 802.1X and DHCP snooping strengthens network security

24-port PoE+ Managed Switch

The RUCKUS ICX 8100-24P is a 1RU managed switch with 24 RJ-45 ports that deliver 10/100/1000 Mbps connectivity and PoE+ power. It provides a 370 W PoE budget with up to 30 W per port under the 802.3at standard. Four 1 GbE SFP uplink ports handle aggregation to the core. The unit is managed through an industry-standard CLI, embedded web interface and DHCP auto-configuration.

Small to mid-size deployments needing PoE+ density

This switch suits offices, classrooms or branch sites that power VoIP phones, wireless APs or cameras from the network edge and want a single management plane for wired and wireless. It is not for environments that need 10 GbE uplinks, nor for cores that require dynamic Layer 3 routing protocols.

370 W PoE budget across 24 ports

The total PoE budget of 370 W is the single figure that decides whether the switch can power every attached device simultaneously. Calculate the aggregate draw of your PoE+ endpoints before specifying this model.

Highlights

  • 24 PoE+ ports deliver up to 30 W each for power-hungry devices
  • 370 W total PoE budget supports dense endpoint deployments
  • 4 SFP uplink ports provide 1 GbE fibre connectivity
  • 42 Mpps forwarding capacity handles heavy traffic loads
  • Managed switch with 802.1X and DHCP snooping strengthens network security

Specifications

BrandFortinet
SeriesRUCKUS ICX 8100
ModelICX 8100-24P PoE
Part NumberICX8100-24P
Switch TypeICX8100-24P
Standards802.1AB LLDP/ LLDP-MED
802.1D MAC Bridging
802.1p Mapping to Priority Queue
802.1s Multiple Spanning Tree (MST)
802.1w Rapid Reconfiguration of Spanning Tree (RSTP)
802.1x Port-based Network Access Control (PNAC)
802.3 Carrier Sense Multiple Access/Collision Detection (CSMA/CD)
802.3ab 1000BASE-T
802.3 10Base-T
802.3ad Link Aggregation (Dynamic and Static)
802.1 AX-2008 Link Aggregation
802.3ae 10 Gigabit Ethernet
802.3af Power over Ethernet
802.3at Power over Ethernet Plus
802.3bz Multigigabit Ethernet
802.3u 100Base-TX
802.3x Flow Control
802.3z 1000Base-SX/LX
802.3 MAU MIB (RFC 22
Network Management TypeManaged
Management FeatureDHCP Auto-Configuration
Configuration Logging
Digital Optical Monitoring
Display Log Messages on Multiple Terminals
Embedded Web Management (HTTP/HTTPS)
Embedded DHCP Server
Industry-standard Command Line Interface (CLI)
RUCKUS SmartZone, RUCKUS One, RUCKUS Unleashed
CLI activation of optional software features
Macro for batch execution
RSPAN
TFTP
TELNET Client and Server
SSH / SSH V2
Bootp
SNMPv1/v2c
DHCP Server and DHCP Relay
SNMPv3 Intro to Framework
Architecture for Describing SNMP Framework
SNMP Message Processing and Dispatching
SNMPv3 Applications
SNMPv3 User-based Security Mo
MAC Address Table32K
Jumbo FramesMaximum jumbo frame size: 9,216 bytes
Packet Forwarding RateForwarding capacity (data rate, full duplex): 42 Mpps
Buffer Memory4 MB
Security802.1X authentication
MAC authentication
Flexible authentication
Web authentication
DHCP snooping
Dynamic ARP inspection
Neighbor Discovery (ND) Inspection
Bi-level Access Mode (Standard and EXEC Level)
EAP pass-through support
IEEE 802.1X username export in sFlow
Protection against Denial of Service (DoS) attacks
Authentication, Authorization, and Accounting (AAA)
MAC Address Locking MAC Port Security
Advanced Encryption Standard (AES) with SSHv2
RADIUS/TACACS/TACACS+
Secure Copy (SCP)
Secure Shell (SSHv2)
Protected Ports
Local Username/Password
Change of Authorization (CoA) RFC 517
PoEYes
QoSQoS priority queues: 8 per port
Quality of Service (QoS):
ACL Mapping and Marking of ToS/DSCP (CoS)
ACL Mapping and Marking of 802.1p
ACL Mapping to Priority Queue
Classifying and Limiting Flows Based on TCP Flags
DiffServ Support
Honoring DSCP and 802.1p (CoS)
MAC Address Mapping to Priority Queue
Priority Queue Management using Weighted Round Robin (WRR), Strict Priority (SP), and a combination of WRR and SP
Layer802.1s Multiple Spanning Tree
802.1x Authentication
Auto MDI/MDIX
BPDU Guard, Root Guard
Dual-Mode VLANs
MAC-based VLANs, Dynamic MAC-based VLAN activation
Dynamic VLAN Assignment
Dynamic Voice VLAN Assignment
Fast Port Span
GVRP : GARP VLAN Registration Protocol
IGMP Snooping (v1/v2/v3)
IGMP Proxy for Static Groups
IGMP v2/v3 Fast Leave
Inter-Packet Gap (IPG) adjustment
Link Fault Signaling (LFS)
MAC Address Filtering
MAC Learning Disable
MLD Snooping (v1/v2)
Multi-device Authentication
Per-VLAN Spanning Tree (PVST/PVST+/PRST)
Mirroring: Port-based, ACL-based, MAC Filter-based, and
Layer 3 FeaturesBase Layer 3 IP routing:
Routing not supported
Static Routing
Shipping weight5.58 kg
Package size442 × 282 × 46 mm

Questions about this item

What SFP modules do I need for the four 1GbE uplink ports?

Use any 1000Base-SX or 1000Base-LX SFP transceivers compliant with 802.3z for the four SFP uplink ports.

Can my existing 10/100 Mbps endpoints still connect to the 24 RJ-45 ports?

Yes, each RJ-45 port auto-negotiates down to 10 or 100 Mbps while still providing PoE+ power when needed.

Which LED pattern confirms the 370 W PoE budget is active after power-up?

The system LED turns solid green and each powered port shows a steady amber PoE indicator when the 370 W budget is operational.
