White square ceiling-mounted wireless access point with smooth matte finish and recessed indicator lights

RUCKUS WIRELESS

RUCKUS WIRELESS 901-R650-WW00 access point

SKU CH-45FF-WGAJ6 MPN 901-R650-WW00

Wi-Fi 6 access point with dual-band 2.4 and 5 GHz radios, six spatial streams, 2.5 GbE uplink and embedded BLE and Zigbee IoT radios

  • StandardsIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE
  • Frequency BandFrequency Band: 2.4 GHz, 5 GHz
  • AntennaInternal
  • Transmitted PowerPower Over Ethernet (PoE) Supported: PoE+
  • Interface1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x USB 2.0 - Type A
  • ComplianceCompliant Standards: EN 61000-4-2, EN 61000-4-3, EN 61000-4-
  • Serve more clients at once with six MU-MIMO spatial streams and 512 concurrent connections
  • Wi-Fi 6 dual-band radios deliver up to 2974 Mbps peak throughput
  • 5 GbE uplink prevents backhaul bottlenecks for full wireless speed
  • Built-in BLE and Zigbee radios unify IoT devices on one platform
  • Flexible management via cloud, on-premises appliances or controller-less operation

Mid-range Wi-Fi 6 access point

The Ruckus R650 is a dual-band wireless access point built for offices, classrooms and retail spaces where many devices connect at once. It supports up to 512 client connections and delivers a peak data rate of 2974 Mbps across six MU-MIMO spatial streams. The unit includes embedded IoT radios for Bluetooth Low Energy and Zigbee, enabling non-Wi-Fi services on the same hardware. Management options span cloud, on-premises appliances or controller-less operation.

2.5 GbE backhaul port

A single 2.5 Gbps Ethernet port with PoE+ provides both power and uplink, ensuring the wired backhaul does not limit the available Wi-Fi 6 capacity. The 1000Base-T label on the specification sheet refers to the base standard, while the 2.5 Gbit/s rate is the operational speed that matches the wireless throughput. No separate power supply is required when a PoE+ switch or injector is present.

Wall-mountable with internal antennas

The access point mounts on a wall or ceiling using the supplied bracket and relies on internal antennas, so there are no external elements to align or damage. Installation consists of connecting the PoE+ cable and adopting the device in the chosen management plane. The only common issue is forgetting to enable the 2.5 Gbps port speed on the switch side, which leaves the link at 1 Gbps and creates a bottleneck.

Highlights

  • Serve more clients at once with six MU-MIMO spatial streams and 512 concurrent connections
  • Wi-Fi 6 dual-band radios deliver up to 2974 Mbps peak throughput
  • 5 GbE uplink prevents backhaul bottlenecks for full wireless speed
  • Built-in BLE and Zigbee radios unify IoT devices on one platform
  • Flexible management via cloud, on-premises appliances or controller-less operation

Specifications

BrandRuckus
Part Number901-R650-WW00
StandardsIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
Frequency BandFrequency Band: 2.4 GHz, 5 GHz
AntennaInternal
Transmitted PowerPower Over Ethernet (PoE) Supported: PoE+
Interface1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x USB 2.0 - Type A
ComplianceCompliant Standards: EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, UL 2043, RoHS, EN 60950-1, WEEE, EN 60601-1-2, EN 62311, EN 50121-4, IEC 61373, EN 50121-1, ISTA 2A
TemperatureMin Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
HumidityHumidity Range Operating: 95% (non-condensing)
FeaturesInternet of Things (IoT)
Internet of Things (IoT) Compatible: Yes
Communications Technology: Bluetooth Low Energy (LE), Zigbee
Features: VLAN support, IPv6 support, wall mountable, Wireless Intrusion Detection System (WIDS), Quality of Service (QoS), IPv4 support, Low Density Parity Check (LDPC), Space Time Blocking Code (STBC), ceiling mountable, Wireless Intrusion Prevention System (WIPS), BeamFlex+ Smart Antenna Technology, 4x4 MU-MIMO technology, Smart Roaming, 4x4 SU-MIMO technology, HotSpot 2.0, WMM Power Save, Smart Mesh technology, Transmit Beamforming
Encryption Algorithm: A
Shipping weight1.11 kg
Package size224 × 193 × 48 mm

Questions about this item

What does the 2974 Mbps peak rate mean when the R650 is installed in a real network?

The 2974 Mbps figure is the maximum theoretical throughput across both radios combined; actual client speeds will be lower and depend on channel width, client capability, interference and the number of simultaneous users.

The AP has a 2.5 GbE PoE port — what does that interface cap in practice?

The 2.5 GbE RJ-45 port limits wired backhaul to 2.5 Gbit/s and supplies power via PoE+, so the Ethernet link will not bottleneck the Wi-Fi 6 radios under full load.

What mounting options does the R650 hardware include?

The unit is designed to be wall-mountable and also supports ceiling-grid brackets; it weighs little enough for standard drop-ceiling rails and requires only the single PoE+ cable for power and data.
