Ricoh
Ricoh PA03811-B025 SP-1130N duplex document scanner
Duplex ADF scanner captures 30 ppm simplex or 60 ipm duplex with a 50-sheet feeder, USB 3.2 and Gigabit Ethernet
- TypeADF (Automatic Document Feeder), Duplex
- Element TypeSingle line CMOS-CIS x 2 (front x 1, back x 1)
- Light SourceRGB LED x 2 (front x 1, back x 1)
- Scanning SpeedSimplex: 30 ppm (200/300 dpi) Duplex: 60 ipm (200/300 dpi)
- Optical Resolution600 dpi
- Max. Document Size8.5" x 14"
- Fast batch capture with 30 ppm simplex and 60 ipm duplex scanning
- 50-sheet ADF handles high-volume jobs without constant reloading
- Scans embossed cards, receipts and legal-length pages up to 8.5 x 14 inches
- Compact footprint 20 percent smaller than comparable scanners saves desk space
- Ethernet and USB 3.2 Gen 1 connections give flexible, stable network or direct attachment
Ricoh SP-1130N Duplex Document Scanner
The Ricoh SP-1130N is a compact desktop scanner with a 50-sheet automatic document feeder. It captures both sides of a page in one pass at up to 60 images per minute at 200 or 300 dpi. Optical resolution reaches 600 dpi. The unit handles media from receipts and embossed cards up to legal-size sheets measuring 8.5 by 14 inches. Connectivity includes USB 3.2 Gen 1 and Gigabit Ethernet for direct network integration. PaperStream IP and Capture software are bundled for image cleanup and batch organisation.
Suited For Small Office Batch Scanning
This scanner fits teams that need fast two-sided digitisation of mixed paperwork without a large footprint. The 50-sheet ADF and legal-size support cover typical invoice, contract and ID card workflows. Gigabit Ethernet allows shared access across a workgroup without a dedicated PC. Buyers who need flatbed scanning for bound books or fragile originals should look at a different form factor. Users requiring daily volumes well beyond the rated duty cycle or higher optical resolution for archival photography will need a production-class device.
Straightforward Setup With Common Pitfalls
Installation consists of connecting the AC adapter, linking USB or Ethernet, and running the setup DVD-ROM on a supported Windows version from Windows 7 through Windows Server 2019. One-push button scanning works after the PaperStream drivers are loaded. The most frequent issue is feeding multi-feed errors when mixing very thin receipts with standard paper in the same batch; separating those jobs avoids jams. Another common snag is the scanner entering auto-standby too aggressively on quiet networks, which is adjusted in the power-management utility.
Highlights
- Fast batch capture with 30 ppm simplex and 60 ipm duplex scanning
- 50-sheet ADF handles high-volume jobs without constant reloading
- Scans embossed cards, receipts and legal-length pages up to 8.5 x 14 inches
- Compact footprint 20 percent smaller than comparable scanners saves desk space
- Ethernet and USB 3.2 Gen 1 connections give flexible, stable network or direct attachment
Specifications
| Brand | Ricoh |
|---|---|
| Series | Image Scanner SP-1130N |
| Model | PA03811-B025 |
| Type | ADF (Automatic Document Feeder), Duplex |
| Element Type | Single line CMOS-CIS x 2 (front x 1, back x 1) |
| Light Source | RGB LED x 2 (front x 1, back x 1) |
| Scanning Speed | Simplex: 30 ppm (200/300 dpi) Duplex: 60 ipm (200/300 dpi) |
| Optical Resolution | 600 dpi |
| Max. Document Size | 8.5" x 14" |
| Automatic Document Feeder (ADF) | Yes |
| ADF Capacity | 50 sheets (A4 80 g/m2 or Letter 20 lb) |
| USB Ports | USB 3.2 Gen 1x1 / USB 2.0 / USB 1.1 |
| Other Ports | 10BASE-T,100BASE-TX,1000BASE-T |
| Power Requirements | AC 100 - 240V, 50 / 60 Hz |
| Power Consumption | Operating Mode: 18W or less Power Saving Mode: 2W or less Auto Standby (Off) Mode: 0.4W or less |
| Operating Systems Supported | Windows 10, Windows 8.1, Windows 7, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2 |
| Features | Simplex: 30 ppm (200/300 dpi) Duplex: 60 ipm (200/300 dpi) 50 page ADF for batch scanning Scans a variety of paper sizes and thickness from embossed cards and receipts up to legal paper length Compact size - 20% smaller than competitive scanners in the category PaperStream IP and PaperStream Capture software for image clean up and organization One-push button scanning capable Multiple connectivity for stable scanning; Ethernet and USB 3.2 |
| Dimensions | 5.20" x 11.70" x 5.30" |
| Weight | 5.50 lbs. |
| Package Contents | SP-1130N Document Scanner AC adapter USB cable Setup DVD-ROM |
| Software Included | PaperStream IP for SP Series (TWAIN/TWAIN x64/ISIS) WIA Driver PaperStream Capture Software Operation Panel Error Recovery Guide ABBYY FineReader for ScanSnap Scanner Central Admin ABBYY FineReader Sprint Network Setup Tool for SP Series SP Series Online Update |
| Shipping weight | 3.99 kg |
| Package size | 394 × 269 × 246 mm |
Questions about this item
Which operating system must the host PC run for the SP-1130N driver to install?
The scanner supports Windows 10, Windows 8.1, Windows 7 and Windows Server 2019, 2016, 2012 R2, 2012 and 2008 R2.
Can the SP-1130N share a Gigabit Ethernet switch with a legacy 100BASE-TX printer?
Yes, the scanner provides 10BASE-T, 100BASE-TX and 1000BASE-T ports, so it will negotiate the highest common speed with each device.
How do I confirm the duplex unit is scanning both sides at the rated 60 ipm?
Run a test batch through the ADF at 200 or 300 dpi and verify the capture software reports approximately 60 images per minute for two-sided originals.
