Stainless steel solenoid valve with conduit and leads

Red Hat

Red Hat EF8314H301 12V DC 3-Way 2-Position Solenoid Valve 1/4 in

SKU CH-VAFW-38ZW6 MPN EF8314H301

A stainless-steel 3-way, 2-position solenoid valve operating on 12 V DC with a 1/16-inch orifice, 1/4-inch NPTF ports and an explosion-proof, watertight Class F coil rated to 130 psi and 149 °F

  • TypeDrain Components
  • MaterialHAWA
  • Stainless steel body resists corrosion in demanding environments
  • 12V DC operation suits low-voltage control systems
  • Explosion-proof and watertight coil enclosure rated for indoor and outdoor use
  • 3-way 2-position design with configurable starting position for flexible flow control
  • 130 psi maximum pressure differential handles air and inert gas applications

12 V DC solenoid valve for air and inert gas

The Red Hat EF8314H301 is a stainless steel solenoid valve that operates on a 12 V DC supply. It uses a direct acting mechanism with a 3-way, 2-position design and a 1/16 in orifice. The coil enclosure is rated Explosion-Proof and Watertight with Class F insulation for indoor or outdoor use.

Suits systems needing configurable 3-way control

This valve fits pneumatic or inert gas circuits that require a 1/4 in NPTF connection and a maximum operating pressure differential of 130 psi. It is not for liquids or for applications that exceed 149 °F fluid temperature or need a larger flow path than the 1/16 in orifice provides.

1/4 in NPTF connection with 1/16 in orifice

The nominal pipe size is 1/4 in with NPTF inlet and outlet threads, while the orifice diameter is fixed at 1/16 in. These two dimensions determine whether the valve matches the required port size and flow capacity for the installation.

Highlights

  • Stainless steel body resists corrosion in demanding environments
  • 12V DC operation suits low-voltage control systems
  • Explosion-proof and watertight coil enclosure rated for indoor and outdoor use
  • 3-way 2-position design with configurable starting position for flexible flow control
  • 130 psi maximum pressure differential handles air and inert gas applications

Specifications

TypeDrain Components
MaterialHAWA
BrandRed Hat
ModelEF8314H301 12/DC

Questions about this item

How much heat does the 12V DC coil generate when the valve runs all day?

The Class F coil insulation is rated for continuous duty at the specified 149°F maximum fluid temperature, so the coil is designed to handle sustained operation without overheating.

What piping and electrical supplies must I already have to install this 1/4 in NPTF valve?

You need 1/4 inch NPTF threaded pipe connections for the inlet and outlet, plus a 1/2 inch conduit fitting to terminate the 18 inch coil leads.

Will the 130 psi pressure rating work with my existing low-pressure air compressor?

Yes, the valve operates from 0 psi minimum up to 130 psi maximum differential, so it is compatible with typical low-pressure shop air systems.
