Brass solenoid valve body with coil enclosure, half-inch pipe threads

Red Hat

Red Hat 8222G076 1/2 in Brass Steam Trap

SKU CH-ECRE-FAFA0 MPN 8222G076

A normally-closed brass solenoid valve with a 1/2 in port, PTFE seal and 2.5 Cv rating for 110/120 V AC steam service

  • TypeDrain Components
  • Normally closed design prevents steam loss until energised
  • Brass body resists corrosion in high-temperature service
  • 1/2 in NPT connection fits standard pipework
  • PTFE seal handles 120 V AC coil heat reliably
  • Cv 2.5 delivers adequate flow for typical steam traps

1/2 in Brass Steam Solenoid Valve

The Red Hat 8222G076 is a normally closed, two-way solenoid valve built for high-temperature service. It suits industrial steam lines and process equipment that require reliable on-off control with a brass body and PTFE seals.

Check voltage and pipe fit before ordering

Confirm that the control circuit supplies 110V AC or 120V AC and that the piping uses a 1/2 in nominal pipe thread. The valve carries a Cv of 2.5 with a 3/8 in orifice, so verify the flow requirement matches this capacity. Ensure the media is compatible with brass and PTFE at the intended operating temperature.

Watertight coil enclosure protects the solenoid

The coil housing is rated watertight, helping the valve withstand wash-down or humid environments without ingress. This enclosure does not change the electrical rating or the pressure limits, which remain as specified for air, inert gas, fuel gas and fuel oil service. California Proposition 65 warnings apply to this product.

Highlights

  • Normally closed design prevents steam loss until energised
  • Brass body resists corrosion in high-temperature service
  • 1/2 in NPT connection fits standard pipework
  • PTFE seal handles 120 V AC coil heat reliably
  • Cv 2.5 delivers adequate flow for typical steam traps

Specifications

TypeDrain Components
BrandRed Hat
Model8222G076

Questions about this item

What is included with the Red Hat 8222G076 valve and what must be purchased separately?

The valve body, solenoid coil, and watertight enclosure are supplied as a single unit. Piping, thread sealant, wiring, and a 110V AC or 120V AC power source are not included.

Which voltage version of the 8222G076 should I select for a standard US mains supply?

The coil is rated for both 110V AC and 120V AC, so a single model covers the common North American mains range.

What does the 2.5 Cv rating mean for steam flow through this 1/2 in valve?

A Cv of 2.5 indicates the valve will pass 2.5 US gallons per minute of water at a 1 psi pressure drop; for steam the actual mass flow depends on inlet pressure and temperature.
